China Asphalt Paver Machine 12.5m Concrete Road Paver for Sale

Shanghai Super-Above Industry Holdings Co., Ltd.
  • Object：Asphalt Concrete Pavement
  • Moving Type：Mobile

Base Info

  • Model NO.：RP1253 Road Paver
  • Mixing Method：Intermittent Compulsory
  • Automatic Grade：Automatic
  • Product Capacity：700t,H
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Driving Speed：0-3km,H
  • Hopper Capacity：15t
  • Max. Paving Thickness：350mm
  • Max Pave Width：12m
  • Moving：Crawler
  • Dimension：6760*2600*3950mm
  • Maximum Paving Speed：18m,Min
  • Rate Power：210,2000 Kw,Rpm
  • Maximum Laydown Rate：700t,H
  • Keyword：Road Paver
  • Weight：23.5-32t
  • Transport Package：Naked or Roro
  • Specification：CE
  • Trademark：Super-above
  • Origin：Jiangsu, China
  • HS Code：8479102100
  • Production Capacity：10000PC,Year

Description

DescriptionUnitRP1253Basic paving widthm2.5Max paving widthm12Max paving thicknessmm350Paving speedm/min0~18transport  speed(China II Engine)Km/h0~3.0transport  speed(China III Engine)km/h0~3.5feed capacityt/h700Hopper capacityt15Gradient ability%20Smoothnessmm/3m0.8slope leveling tolerance%-5Engine type (China II Engine)/BF6M1013Engine type (China III Engine)/BFM8 4VFuel tankL300Generator output (China II Engine)Kw183Generator output (China III Engine)kw210Total weight t23.5~32.0dimensiontmm6760*2600*3950China Asphalt Paver Machine 12.5m Concrete Road Paver for Sale
