Sdlg G9290/G9290f New Appearance Multi-Purpose Motor Grader Widely Used in Highway Construction with Rear Ripper and Front Dozer

Shandong Lingong Construction Machinery Co., Ltd
  • Certification：TUV, UL, ISO, RoHS
  • Condition：New
  • Application：Railway, Mine, Farmland, Highway
  • Transmission：Hydraulic
  • Walking Mode：Wheeled
  • Type：Large Grader

Base Info

  • Model NO.：G9290
  • Overall Working Weight：23000kg
  • Inclination Angle of Front Wheel：50
  • Cutter Diameter：1626mm
  • Cutter Size：4267*680*25mm
  • Min. Turning Radius：825mm
  • Lift Height of Blade：450mm
  • Cutting Depth of Blade：825mm
  • Max. Tractive Force：145.5kn
  • Max. Speed：31.8km,H
  • Engine Brand：Sdlg
  • Rated Power：211kw
  • Transport Package：RO-RO, Container
  • Specification：10170*2910*3390mm
  • Trademark：SDLG
  • Origin：Linyi, Shandong, China
  • Production Capacity：50000unit,Year

Description

Overall dimension L*W*H10170*2910*3390mmMin ground clearance of front axle610mm Ground clearance of rear axle560mm Wheelbase7080mm Wheel tread2390mmBalance box center distance1648mmOverall parameters Overall working weight23000kgMax. inclination angle of front wheel18°Max. swing angle of front axle16°Max. steering angle of front wheel50°Steering angle of articulated frame21°Cutter diameter1626mmCutter size4267*680*25mmSwing angle of blade360°Lift height of blade450mmCutting depth of blade825mmBlade cutting angleFront 40/rear 5°Blade lateral distance673/673mmMax. tractive force145.5kNEngine ModelSD130B13-130Type Four-stroke, Inline, water-cooled, direct injectionRated Power@Revolution Speed 2100r/minDisplacement 12780mL Cylinder bore × stroke 131*158mm Emission standard Tier3Max. torque 1290/900-1500Transmission systemTransmission typeHTE840STorque converterMechanical power shift gearboxGearsForward 6 reverse 4Hydraulic system Type Piston PumpSystem pressure20MPaFill capacity Fuel 410L Hydraulic oil 120L Sdlg G9290/G9290f New Appearance Multi-Purpose Motor Grader Widely Used in Highway Construction with Rear Ripper and Front Dozer
