1.6ton Zl16 China Micro Mini Shovel Machine Articulated Small Loader

Weihai Titan Heavy Machinery Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：1-3t
  • Transmission：Hydraulic - Mechanical
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Model NO.：TL16
  • Type：Small Loader
  • Operating Weight：4175kg
  • Bucket Capacity：0.8cbm
  • Engine：Xinchai A498bt1(Euro III)
  • Rated Power：37kw
  • Max. Dumping Height：2700mm
  • Rated Speed：2500r,Min
  • Transport Package：Nude in Container
  • Specification：5100*1700*2770
  • Trademark：TITAN
  • Origin：China
  • HS Code：84295100
  • Production Capacity：1000,Year

Description

TL16 MINI WHEEL LOADER SPECIFICATIONITEMSPECIFICATION1.0 Engine details:  ModelXinchai A498BT1(EURO III)Engine typeIn-line arrangement, water-cooled, four-cycle diesel EngineRated Power36.8KW Rated Speed2400 r/min (rpm)Fuel Consumption ratio in standard working condition230g/kw.h2.0 Transmission System TypeFixed-spindle Power shiftShift gear control oil pressure1.2~1.5MPaRated input speed2500 (rpm) 3.0 Bucket  Bucket Capacity0.8m3  Bucket width1800mmBucket typeHeavy-duty bolt on teeth Max. Breakout Force36.8KN  Rated Load1600kg  Operating Weight 4175kg4.0 Overall Dimensions  Overall Length (Bucket on ground position)5100mmOverall Height 2770mmGround to Cab Top2770mmDumping Height2700mmMin. Base to the Ground290mmOverall Width1800mm5.0 Operating Specifications  Steering SystemArticulated Frame with hydraulic power steeringMin Turning Radius4500mmDriving SystemHydraulic converter6.0 Brake System  Service BrakeFour Wheel drive hydraulic disc brake.Parking BrakeHand operated  7.0 Tyre Model20.5/70-168.0 Wheelbase2100mm


The standard equipment:

----Xinchai A498BT1(EURO III)
----4 Cylinder Engine.
----Automatic with Torque Converter.
----4 Wheel Drive.
----Standard Bucket.
----Luxury Cabin.
----Adjustable Steering Wheel.
----220V Engine Pre-heater.
----Cabin Heater.
----Air Pre-heater.
----Lock For Lifting And Steering Cylinder.
----Hydraulic Check System.
----Quick Hitch.
----Mechanical Joystick.
----Easy-damaged Spare Parts.
----Optional equipments.
----Extra Hydraulic Line.
----LED Lights.
----Varta Anti-free Battery.
