Zl16 1.6ton China Payloader Machine Front End Shovel Loader
Weihai Titan Heavy Machinery Co., Ltd.- Certification:TUV, UL, ISO, RoHS, CE
- Condition:New
- Rated Load:1-3t
- Transmission:Hydraulic - Mechanical
- Load and Unload Mode:Front Discharge
- Walking Mode:Wheeled
Base Info
- Model NO.:TL16
- Type:Small Loader
- Operating Weight:4175kg
- Bucket Capacity:0.8cbm
- Engine:Xinchai A498bt1(Euro III)
- Rated Power:37kw
- Max. Dumping Height:2700mm
- Running Speed:36.8kph
- Transport Package:Nude in Container
- Specification:5100*1700*2770
- Trademark:TITAN
- Origin:China
- HS Code:84295100
- Production Capacity:1000,Year
Description
TL16 WHEEL LOADER SPECIFICATION1.0 Engine details: Model Xinchai A498BT1(EURO III) Engine type In-line arrangement, water-cooled, four-cycle diesel Engine Rated Power 36.8KW Rated Speed 2400 r/min (rpm) Fuel Consumption ratio in standard working condition 230g/kw.h 2.0 Transmission System Type Fixed-spindle Power shift Shift gear control oil pressure 1.2~1.5MPa Rated input speed 2500 (rpm) 3.0 Bucket Bucket Capacity 0.8m3 Bucket width 1800mm Bucket type Heavy-duty bolt on teeth Max. Breakout Force 36.8KN Rated Load 1600kg Operating Weight 4175kg 4.0 Overall Dimensions Overall Length (Bucket on ground position) 5100mm Overall Height 2770mm Ground to Cab Top 2770mm Dumping Height 2700mm Min. Base to the Ground 290mm Overall Width 1800mm 5.0 Operating Specifications Steering System Articulated Frame with hydraulic power steering Min Turning Radius 4500mm Driving System Hydraulic converter 6.0 Brake System Service Brake Four Wheel drive hydraulic disc brake. Parking Brake Hand operated 7.0 Tyre Model 20.5/70-16 8.0 Wheelbase 2100mm
---Standard Bucket or 4 in 1 bucket and pallet fork,
---Hydraulic Torque Converter Transmission,
---Floating Function,
---Pilot joystick control,
---130W Heater, 220V Engine Heater,
---Rops&Fops Cabin,
---Tipping Cabin,
---Luxury Cabin Inside,
---Backward Imagine,
---Comfortable Seat,
---Adjustable Steering Wheel,
---Wheel Reducer Axle,
---Air Brake,
---Lock for Lifting and Steering Cylinder,
---Hydraulic Pressure Check System,
---Parallel Linkage,
---Free Service Spare Parts etc.
The standard equipment:
---Standard Bucket or 4 in 1 bucket and pallet fork,---Hydraulic Torque Converter Transmission,
---Floating Function,
---Pilot joystick control,
---130W Heater, 220V Engine Heater,
---Rops&Fops Cabin,
---Tipping Cabin,
---Luxury Cabin Inside,
---Backward Imagine,
---Comfortable Seat,
---Adjustable Steering Wheel,
---Wheel Reducer Axle,
---Air Brake,
---Lock for Lifting and Steering Cylinder,
---Hydraulic Pressure Check System,
---Parallel Linkage,
---Free Service Spare Parts etc.
