Popular Market Xe370ca 37ton Hydraulic Wheel Excavator Track Excavator
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Free Spare Parts
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：XE370CA
- Drive Type：Diesel
- Bucket Capacity：1.0~1.5m³, 1.4-1.8m3
- Size：Large-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Model：Lsuzu
- Operating Weight：36600kg
- Output Power：190.5,2000kw, R,Min
- Torque/Speed：872.8,1700n.M
- Displacement：7.79L
- Machine Weight：36600kg
- Maximum Digging Depth：6786mm
- Transport Package：Nude
- Specification：11386*3190*3530mm
- Origin：Jiangsu, China
- HS Code：8429521200
- Production Capacity：1000pes,Year
Description
Overview
Product Description
Detailed Photos
Product ParametersDescription
| Description | Unit | Parameter value | |
| Operating weight | kg | 36600 | |
| Bucket capacity | m³ | 1.4~1.8 | |
| Engine | Model | Engine | AA-6HK1XQP |
| Direct injection | --- | √ | |
| Four strokes | --- | √ | |
| Water cooling | --- | √ | |
| Turbo-charging | --- | √ | |
| Air to air intercooler | --- | √ | |
| No. of cylinders | --- | 6 | |
| Output power | kW/ r/min | 190.5/2000 | |
| torque/speed | N.m | 872.8/1700 | |
| Displacement | L | 7.79 | |
| Travel speed(H/L) | km/h | 5.4/3.2 | |
| Main performance | Gradeability | % | 70 |
| Rotary speed | r/min | 9.6 | |
| Ground pressure | kPa | 66.6 | |
| Bucket digging force | kN | 263 | |
| Arm digging force | kN | 225 | |
| Hydraulic system | Main pump | -- | K5V160DTH |
| Rated flow of main pump | L/min | 2×320 | |
| Main safety valve pressure | MPa | 34.3/37 | |
| Pressure of pilot system | MPa | 3.9 | |
| Oil Capacity | Fuel tank capacity | L | 630 |
| Hydraulic tank capacity | L | 320 | |
| Engine oil capacity | L | 28 | |
| Appearance size | Overall length | mm | 11386/6.4m boom,11186/6.2m boom |
| Overall width | mm | 3190 | |
| Overall height | mm | 3530/6.4m boom,3676/ 6.2m boom | |
| Width of platform | mm | 2950 | |
| Length of crawler | mm | 5035 | |
| Overall width of chassis | mm | 3190/600 Crawer,3290/700 Crawer, | |
| Width of crawler | mm | 600 | |
| Wheel base of crawler | mm | 4040 | |
| Crawler gauge | mm | 2590 | |
| Clearance under counterweight | mm | 1197 | |
| Min. ground clearance | mm | 500 | |
| Min. rear-end swing radius | mm | 3570 | |
| Max. digging height | mm | 10123 | |
| Working scope (2.71m arm) | Max. dumping height | mm | 6947 |
| Max. digging depth | mm | 6927 | |
| Max. digging depth at the range of level 8 feet | mm | 6709 | |
| Max. vertical wall digging depth | mm | 5312 | |
| Max. digging reach | mm | 10470 | |
| Min. swing radius | mm | 4424 | |
| Working scope (2.5m arm) | Max. digging height | mm | 9891 |
| Max. dumping height | mm | 6820 | |
| Max. digging depth | mm | 6786 | |
| Max. digging depth at the range of level 8 feet | mm | 6666 | |
| Max. vertical wall digging depth | mm | 4914 | |
| Max. digging reach | mm | 10414 | |
| Min. swing radius | mm | 4416 | |
| Worker Standard | Length of boom | mm | 6400 |
| Length of arm | mm | 2670 | |
| Bucket capacity | m³ | 1.6 | |
| Worker Optional | Length of arm | mm | 2900/3200/4000 |
| Bucket capacity | m³ | 1.4/1.5/1.8 |
