• Model NO.：LT12J
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Engine：Wd10g270e201
• Max.Dumping Height：3600mm
• Rated Power：178kw,2200rpm
• Overall Length：8600mm
• Wheel Base：3550mm
• Color：Yellow
• Cycling Time：14s
• Tire Type：26.5-25
• Transport Package：Container or by Bulk
• Specification：8600*3130*3550mm
• Trademark：LTMG
• Origin：China
• HS Code：8429510000
• Production Capacity：800sets,Year

Model LT12JOperating weight kg22,000Engine model WD10G270E201Rated engine powerkw178Rated rotate speedr/nin2200Max.torqueN.m920Max.dumping heightmm3600Rated loadkg12,000NO.of shifts Forward 4 For Reverse 2Driving speed   Forward/Reverse 1km/h0-6.5Forward/Reverse 2km/h0-12.3Forward/Reverse 3km/h0-24Forward/Reverse 4km/h0-41Grade ability ≥25°Turning angle  35°±1°Overall length mm8600Overall width mm3130Overall height mm3550Wheel basemm3550Track base mm2510Torque converter  Model: YJ375X3 ratio:3.166Cycling time S14Tire type  26.5R25

Product Features

1.Safe:
Brake systems: Four wheel double-line caliper disc braking system with a gas container in the back as well as Our exclusive auto Cooling Technology on brake system double assure the reliability and safety. The rear view camera and ROPS/FOPS cab are optional.

2.Energy-efficient:
Hydraulic systems: To adopt confluence of dual-pump confluence and diffluence technology, rational use of engine power, reduce energy consumption effectively. Independent transmission oil and hydraulic oil cooling improve the hydraulic system stability.

3.Beautiful and comfortable:
Pressurized cab: Cab with broad view, large space and noise-isolation and vibration absorber meets all kinds of operation. Radio with MP3 function and speaker and the Joystick control system(Optional)ensure easy operation and more comfortable.

4.Reliable and Steady:
Steering system: The coaxes flow-amplified, hydraulic compensated steering system makes operation easy and performance reliable.
The heavier counterweight, long wheelbase, heighten ground clearance ensure that the machine could adapt to various tough condition.

5.Durable:
Floating forks, tire chain, log grapple, block fork, snow blade, grass fork, enlarged bucket and teeth etc.


After sales service

Nowadays more than100 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
