Sany Hbt6013c-5s 65m3/H Construction Machine Diesel Trailer Pump Price

SANY GROUP CO., LTD.
  • Type：Concrete Pump
  • Shotcrete Type：Wet
  • Machining Process：Hydraulic
  • Structure：S-Valve
  • Productivity：40m3,H
  • Feeding Height：1420

Base Info

  • Model NO.：HBT6013C-5S
  • Vibrating Amplitude：0.7m3
  • Certification：ISO9001: 2000
  • Condition：New
  • Color：Yellow
  • Max.Delivery Pressure(Theoretical) Low/H：8,13 MPa
  • Max.Concrete Output(Theoretical) Low/Hig：65,40 M3,H
  • Engine Rated Power：114 Kw
  • Delivery Cylinder Bore*Strok：200X 1400 mm
  • Hopper Capacity*Feeding Height：0.7X1320 M3,mm
  • Dimension (L*W*H)：6730X2100X2600 mm
  • Gross Weight：6000 Kg
  • Max.Aggregate Size 150mm Pipe：50mm
  • Max.Aggregate Size 125mm Pipe：40mm
  • Slump of Concrete：100-230mm
  • Transport Package：Grouting Mortar Pump Comply with Export Packaging
  • Specification：trailer pump
  • Trademark：SANY
  • Origin：Cn
  • HS Code：84134000
  • Production Capacity：20000 Sets

Description

rated power90kWMax.delivery pressure(theoretical) Low/High pressure8/13 MpaMax.concrete output(theoretical) Low/High pressure65/40 m3/hDelivery cylinder Bore*StrokΦ200× 1400mmHopper capacity*Feeding height0.7×1320 m³/mmDimension (L*W*H)6185×2100×2100 mmGross weight5790 kgMax.aggregate size Φ150mm delivery pipe50 mmMax.aggregate size Φ125mm delivery pipe40mmTypeS valveSlump of concrete100~230mm
