• Model NO.：XN25
• Drive Type：Electric Drive
• Bucket Capacity：0.05cbm
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Hydraulic Oil Tank Capacity：9.5L
• Fuel Tank Capacity：10L
• Hydraulic Pressure：2*16T MPa
• Displacement：3*9.6L,Min
• Lifting Capacity (Height/Depth)：225,225mm
• Ground Pressure：24.5kpa
• Swing Speed：8.2rpm
• Gradeability：30deg
• Travelling Speed(High/Low)：2.9,1.5km,H
• Length to Center of Rollers：975mm
• Track Width：180mm
• Max. Digging Force(Bucket)：9.4kn
• Max. Digging Force(Arm)：5.8kn
• Tail Swing Radius：750mm
• Front Swing Radius：1221mm
• Transport Package：Nude Packing
• Specification：2640*2250*750mm
• Trademark：Crawler Excavator
• Origin：Shandong, China
• HS Code：8429521100
• Production Capacity：1000 Unit,Units Per Month

Product OverviewProduct Paramenters

OPERATING RANGE

Max. Digging depth

2400 mm

Max. Vertical digging depth

1890 mm

Max. Digging height

3910 mm

Max. Dumping height

2675 mm

Max. Digging radius on ground

4080 mm

Min. Rotation radius

1780 mm

Max. Upgrade height of bulldozer blade

235 mm

Max. Digging depth of bulldozer blade

225 mm
