• Model NO.：9055E
• Drive Type：Electric Drive
• Bucket Capacity：0.2cbm
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Machine Weight：5700 Kg
• Standard Bucket Capacity：0.2cbm
• Emission Standards：National Three
• Rated Power (Rated Speed)：36.2kw@2100rpm
• Net Power (Rated Speed)：33.7kw@2100rpm
• Maximum Torque (Torque/Speed)：212.7,1260 N·m
• High/Low Driving Speed：4.2~2.7 Km,H
• Swing Speed：10.3 Rpm
• Ground Pressure：31.67 Kpa
• Wheelbase of Chassis：2230mm
• Maximum Digging Height：5790 mm
• Maximum Digging Radius：6205 mm
• Maximum Digging Depth：3875 mm
• Aximum Unloading Height：4135 mm
• Long (Transport State)：5900 mm
• Transport Package：Nude Packing
• Specification：CLG9055E
• Trademark：Crawler Excavator
• Origin：Jiangsu, China
• HS Code：8429521200
• Production Capacity：1000 Unit,Units Per Month

Machine weight

5700 kg

power

36.2kW@2100rpm

Standard bucket capacity

0.2 m³

engine model

4TNV94L

Emission Standards

National Three

Type

4-cylinder in-line, water-cooled, direct injection

Rated power (rated speed)

36.2kW@2100rpm

Net power (rated speed)

33.7kW@2100rpm

Maximum torque (torque/speed)

212.7/1260 N·m

cooling method

Water cooling

High/low driving speed

4.2~2.7 km/h

Swing speed

10.3 rpm

Gradeability

35 °

Ground pressure

31.67 kPa

Stick Rated/Pressurized Digging Force (ISO)

31 kN

Bucket rated/pressurized digging force (ISO)

41 kN

Long (transport state)

5900 mm

Overall width (standard track configuration)

1900 mm

High (transport state)

2630 mm

Minimum ground clearance

350 mm

Wheelbase of chassis

1990 mm

Underframe gauge

1500 mm

Track width (standard)

400 mm

Maximum digging height

5790 mm

Maximum digging radius

6205 mm

Maximum digging depth

3875 mm

Maximum unloading height

4135 mm
