Topmac Brand 510 Lt Concrete Mixer with Winch
Jurong Topall Machinery Co., Ltd.- After-sales Service：12 Month
- Warranty：12 Month
- Type：Concrete Mixer
- Shotcrete Type：Wet
- Machining Process：Vacuum
- Structure：Spiral Type
Base Info
- Model NO.：TDCM510-11DL
- Productivity：10cbm,Hour
- Feeding Height：1400mm
- Vibrating Amplitude：0.8mm
- Certification：ISO9001: 2000, CE
- Condition：New
- Color：Yellow
- Keyword：Concrete Mixer
- Model：Tdcm510
- Power：Diesel Engine Drive Concrte Mixer
- Application：Mixer Concrete
- Transport Package：Nu Nude
- Specification：Drum Capacity: 510L
- Trademark：TOPMAC
- Origin：Jiangsu, China
- HS Code：8474310000
- Production Capacity：1000 Unit,Year
Description
Basic Info.
Model NO. TDCM510-11DL Productivity 10cbm/Hour Feeding Height 1400mm Vibrating Amplitude 0.8mm Certification ISO9001: 2000, CE Condition New Color Yellow Keyword Concrete Mixer Model Tdcm510 Power Diesel Engine Drive Concrte Mixer Application Mixer Concrete Transport Package Nu Nude Specification Drum Capacity: 510L Trademark TOPMAC Origin Jiangsu, China HS Code 8474310000 Production Capacity 1000 Unit/YearProduct Description
Tilting Drum Concrete Mixer With Winch/Elevator And AccssoriesModel TDCM510-11DL
Descriptions
Mixer with hoist system, Which is the mixer and winch designed together, 2 Functions can be realized in one machine. And single diesel engine can drive both the mixer and the hoisting system.
The hoist frame is fixed on the building, so the hoist system goes up with the building. It can lift not only the mixture ,also blocks,sand; or other construction material.
Advantages
1. Winch / Elevator: The winch is placed in an innovative way to minimize the operating hazards of the bucket and the barrel. Our design of the winch includes automatic breaking and a safety cover around the winch to reduce any damage to the sprockets in case the winch-rope breaks.
2. Other Features:
Wheel break
Drum lock
Squared drum nut with a screw to avoid bearing damage
All sprockets are manufactured by machines
A cover around the pinion gear, the steering gear, the cable buckets, and the
elevator to insure operator safety and durability of the mixer
Technical Parameters
| Model | TDCM510-11DL |
| Power | Changfa CF1100BNM Diesel Engine |
| Power source | Diesel Or Electric Motor |
| Drum total volume | 510 L |
| Unmixed capacity | 325 L |
| Mixed capacity | 200 L |
| Mixing time | 40 sec. |
| Capacity per hour | 6~8 cbm |
| Dimension | 1930×2300×2950mm |
| Steel thickness of drum | 4mm |
| Operation | Manual Feed |
| Weight | 1250kg/1300kg |
| Lift high | 24m |
| Lift weight | 150L |
| Double framework distance | 2000mm |
| 1×20' container can be loaded with | 3 Units |
| 1×40H' container can be loaded with | 8 Units |
