Zoomlion 7.5 Ton Crawler Hydraulic Excavator (ZE75E-10)
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：ZE75E-10
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Rated Power：46.3,2200 Kw,Rpm
- Digging Force of Bucket (ISO)：56kn
- Max. Digging Reach：6270mm
- Max. Digging Depth：4046mm
- Max. Digging Height：7003mm
- Transport Package：Nude Package
- Specification：7500kg
- Trademark：Zoomlion
- Origin：China
- HS Code：8429521200
- Production Capacity：50units,Month
Description
Overview
Product Description Items Units ZE75E-10 Basic Technical Data Operating Weight kg 7500 Standard Capacity m³ 0.3 Slewing Speed r/min 11.5 Traveling Speed(high/low) km/h 4.8/2.9 Max. Drawbar Pull kN 64.3 Digging Force of Bucket kN 54 Digging Force of Stick kN 40
Engine
DimensionsLength mm 6149 Width mm 2280 Height mm 2565 Tail Slewing Radius mm 1775 Track Gauge mm 1750 Length of Track On Ground mm 2200 Operating Range Max. Digging Radius mm 6270 Max. Digging Reach mm 6119 Max. Digging Depth mm 4046 Max. Digging Height mm 7003 Max. Dumping Height mm 5128
Product Parameters
Engine
Dimensions
