160HP Forest Lumbering Bulldozer 16f Dozer with Winch to Pull Logs

Hubei Fotma Machinery Co., Ltd.
  • After-sales Service：Best
  • Warranty：2 Year
  • Type：Universal Type
  • Transmission：Hydraulic Transmission
  • Walking Mode：Crawler
  • Load and Unload Method：Front Discharge

Base Info

  • Model NO.：HMD16F
  • Engine Power：147~515kw
  • Certification：ISO9001: 2000
  • Condition：New
  • Color：Yellow
  • Engine：Weichai
  • Power：160HP
  • Function：Pull Log
  • Transport Package：Bulk
  • Specification：5140*3388*3180
  • Trademark：FOTMA
  • Origin：China
  • Production Capacity：50,Month

Description

Basic Info.

Model NO. HMD16F Engine Power 147~515kw Certification ISO9001: 2000 Condition New Color Yellow Engine Weichai Power 160HP Function Pull Log Transport Package Bulk Specification 5140*3388*3180 Trademark FOTMA Origin China Production Capacity 50/Month

Product Description

Forest Lumbering Bulldozer 160HP dozer with Winch to Pull logs

160HP Forest Lumbering Bulldozer 16F Dozer with Winch to Pull Logs

The HMD16F forest lumbering type bulldozer is specially designed for operations in wooded areas. The HMD16F has advanced performance, high reliability, low fuel consumption and convenient maintenance. It's equipped with a ROPS canopy and cab.The HMD16F has excellent maneuver ability and self-rescue capabilities. The HMD16F easily adapts to logging, stacking, hauling and transporting work in wooded areas.

ModelHMD16F
Engine modelWeichai WD10G178E25
Rated power(kw/rpm)131/1850 kw/rpm
Displacement(L)9.726
Max.torque(N.m/rpm)830/1000-1200
Operating weight(Kg)16800
Dimension(no ripper)(mm)5200×3440×3260
Min ground clearance(mm)405
Ground pressure(MPa)0.063
Track shoe width(mm)510
Track gauge(mm)1880
Dozing capacity( m³)4.5
Blade width(mm)3440
Blade height(mm)1150
Max drop below ground(mm)540
Pitch(mm)203.2
Quantity of track link39
Quantity of Carrier rollers4
Quantity of Track rollers14
 Max pressure(MPa)14
Discharge(L/min)213
Max tractor force(KN)146
Grade ability(°)30
Forward(km/h)3.29/5.82/9.63
Reverse(km/h)4.28/7.59/12.53
