• Model NO.：Wheel Loader
• Transmission：Hydraulic
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Load and Unload Method：Front Discharge
• Color：Orange
• Engine Power：147~515kw
• Scraper Type：Pull Scraper
• Transport Package：Naked in Container
• Specification：CE
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000PCS,Year

ItemUnitSpecificationRated operating loadkg3000Bucket capacitym³1.5~2.5Machine weightkg10600±200Dump clearance at maximum liftmm2770~3260Reach at maximum liftmm1010~1210Wheel basemm2600Treadmm1850Height of hinge at maximum lift heightmm3830Working height(fully lifted)mm4870Max.breakout forcekN130Max.horse powerkN95Hydraulic cycle time-raises5.5Total hydraulic cycle times10Min. turning radius over tyresmm5165Articulation angle°35±1Gradeability°28Tyre size 17.5-25-12PROverall machine dimension L×W×H 7050×2482×3118Model WP6G125E22Emission standards Emission 2Rated Power/SpeedkW/rpm92/2300Fuel TankL170Hydraulic TankL170Travel speed1-gear(F/R)km/h8/102-gear(F/R)km/h13/303-gear(F)km/h24/-4-gear(F)km/h40/-

 Advantages
1. The extended wheelbase and the classic 3rd generation loader structure realize higher working capacity, smaller turning radius, and lower wear of rear wheels.
2. Box frame structure of super-strong carrying capacity
3. Comprehensive optimized working device
4. High energy-conservation and efficiency
5. High safety and comfort - The full-view cab sufficiently takes in consideration the human-machine functions to realize high operation safety and comfort.
6. Convenient maintenance - Undertaking the concept of "ground maintenance", all maintenance locations are scientifically arranged to ease the checking and maintenance.

I . The loader adopts the single-stage-4-element hydraulic torque converter and the planetary power gearshift transmission box,
which can automatically adjust the output torque. The high-speed light-load operating mode can automatically be shifted to
low-speed heavy-load operating mode
II . Optimized and improved design of work unit, making the unit lifting capacity , digging force and unloading height as well as total
cycle time at or better than the national figures for high-quality product
IV . The hydraulic system of the working unit adopts soft shaft operation with preset operating valve, which is featured with small
pressure loss, easy and reliable operation
V . Large-vision and fully enclosed driver cab is equipped , with luxury automobile interior decoration, standard heating and
ventilation equipment(air conditioner is optional)
VI . Several devices are optional according to the customer and different working condition, such as the joystick .  Rops/Fops
coal bucket, rock bucket and log grapple
