Tysim Kr110d/a Hydraulic Pile Driver Machine Mini Pile Driving Rotary Drilling Rig
TYSIM Piling Equipment Co., Ltd.- After-sales Service：Supported
- Warranty：1 Year
- Type：Pressure Pile Driver
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Hydraulic Hammer
- Power Source：Diesel
Base Info
- Model NO.：KR110A,D
- Certification：CE, ISO 9001:2000
- Condition：New
- Torque：110 Kn.M
- Max. Diameter：1200 mm
- Max. Drilling Depth：20 M
- Ocerall Weight：32 T
- Main Pull：100 Kn.M
- Transport Package：Nude Pack
- Specification：32 t
- Trademark：tysim
- Origin：Jiangsu, China
- HS Code：8431499900
- Production Capacity：30pieces,Month
Description
CFA construction method Max. diameter 1200mm Max. drilling depth 20m Main winch pull force 100 kN Rotary drilling construction method Max. Diameter 1500 mm Max. drilling depth 37 m Main winch line pull 120 kN Main winch line speed 78 m/min Working parameters Max. torque 110 kN.m Auxiliary winch line pull 35 kN Auxiliary winch line speed 40 m/min Mast inclination(lateral) ±3° Mast inclination(forward) 5° Max. operating pressure 35 MPa Pilot pressure 3.9 MPa Travel speed 1.5 km/h Traction force 230 kN Operating size Operating height 12370 mm Operating width 3600/3000 mm Transport size Transport height 3500 mm Transport width 2600/3000 mm Transport length 13960 mm Total weight Overall weight 32 t
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is half a year or 1000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
Product Details
1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice
Type: New & Used
Brand: CAT, JCM, SINOMACH, SANY, XCMG and other
2. Hydraulic Parts-----Famous Brands
Gearbox Reducer: Imported REXROTH
Main Pump & Valve: Imported KAWASAKI (Japan)
Hose: Imported
3. Structure Parts-----Professional Structure Parts Supplier for XCMG
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
