Popular Sale Backhoe Loader Wz30-25
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE, ISO9001: 2000
- Condition：New
- Rated Load：9500kg
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：WZ30-25
- Type：Small Loader
- Dimension：5600* 2200*2700 (mm)
- Rated Speed：2200 (R,Min)
- Weight：7200 (Kg)
- Usage：Universal Type
- Scraper Type：Pull Scraper
- Load and Unload Method：Front Discharge
- Engine Power：74~147kw
- Color：Yellow
- Transport Package：Nude Packing
- Specification：CE, ISO
- Trademark：ORIEMAC
- Origin：Jiangsu, China
- Production Capacity：500,Month
Description
Basic Info.
Model NO. WZ30-25 Type Small Loader Dimension 5600* 2200*2700 (mm) Rated Speed 2200 (R/Min) Weight 7200 (Kg) Usage Universal Type Scraper Type Pull Scraper Load and Unload Method Front Discharge Engine Power 74~147kw Color Yellow Transport Package Nude Packing Specification CE, ISO Trademark ORIEMAC Origin Jiangsu, China Production Capacity 500/MonthProduct Description
Popular sale backhoe loader WZ30-25
1. Bucket capacity: 1cbm
2. Digger capacity: 0.3cbm
3. Engine: 65kw YC4B90
4. Operation weight: 9500kg
| Weight | 7200 (kg) |
| Overall dimensions (L*W*H) | 5600* 2200*2700 (mm) |
| Bucket width | 700 (mm) |
| Digging bucket capacity | 0.25 (m³) |
| Wheel base | 2300 (mm) |
| Mini. ground clearance | 250 (mm) |
| Loading bucket capacity | 0.96 (m³) |
| Max. dump height | 2600 (mm) |
| Dump distance | 700 (mm) |
| Max.dumping height | 2600 (mm) |
| Dumping reach | 700 (mm) |
| Any place unload degree | 45 (°) |
| Max. raise force | 60 (kN) |
| Mix. swing radius | 6000 (mm) |
| Max. digging depth | 3500 (mm) |
| Max. digging radius | 5600 (mm) |
| Max. grade ablity | 20 (°) |
| System pressure | 18Mpa |
| Engine information | |
| Model | Cummins B3.3T-C80 |
| Rated power | 60 (KW) |
| Rated speed | 2200 (r/min) |
| Type specifiction | |
| Front tyre | 10-16.5 |
| Rear tyre | 15-19.5 |
