XCMG Brand New Construction Machinery 3m3 Wheel Loader Lw300kn 3 Ton Front End Loader Price
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service：Overseas service center available
- Warranty：1Year
- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic - Mechanical
Base Info
- Model NO.：LW300KN
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Dump Clearance at Max Lift：3100~3780mm
- Rated Power/Speed：92,2000kw,Rpm
- Specification：7245*2482*3320mm
- Trademark：XCMG
- Origin：Xuzhou, Jiangsu, China
- Production Capacity：1000,Year
Description
Overview
Product Description
Tilt cylinder bore of 160mm, enlarge the boom cylinder bore from 110mm to 125mm, and increase the boom lifting force by 29%.
12-ton strong tilt drawing force guarantees the outstanding adaptation to various tough conditions.
7-ton strong boom lifting force ensures various operation methods of high intensity.
Long service life
The key articulated positions feature two-stage dust-proof, less abrasion and longer service life.
Wear resistant blade and bucket teethfeature longer service life.
The hydraulic pipe adopts 24° cone and O ring, settling the issue of leakage.Product ParametersDescriptionUnit LW300KN Rated operating load kg 3000 Bucket capacity m³ 1.5~2.5 Machine weight kg 10900±200 Dump clearance at maximum lift mm 2770~3260 Reach at maximum lift mm 1010~1210 Wheel base mm 2900 Tread mm 1850 Height of hinge at maximum lift height mm 3830 Working height(fully lifted) mm 4870 Max.breakout force kN 130 Max.horse power kN 95 Hydraulic cycle time-raise s 5.4 Total hydraulic cycle time s 9.3 Min. turning radius over tyres mm 5170 Articulation angle ° 38±1 Gradeability ° 28 Tyre size 17.5-25-12PR Overall machine dimension L×W×H mm 7245×2482×3320 Model WP6G125E201 Emission standards Emission 2 Rated Power/Speed kW/rpm 92/2000 Fuel Tank L 170 Hydraulic Tank L 175
Company Profile
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
LW300KN is the popular XCMG loader, the updaged edition of ZL30E (LW321F). With the features of maturity and reliability of the old model, LW300Fis improved all round, and leads in the same kind of product. LW300F adopts metal cab and hood, and electrophoretic coating. The machine features high efficiency, strong power, long service life and comfortability, and is applicable to various conditions.
Great strengthTilt cylinder bore of 160mm, enlarge the boom cylinder bore from 110mm to 125mm, and increase the boom lifting force by 29%.
12-ton strong tilt drawing force guarantees the outstanding adaptation to various tough conditions.
7-ton strong boom lifting force ensures various operation methods of high intensity.
Long service life
The key articulated positions feature two-stage dust-proof, less abrasion and longer service life.
Wear resistant blade and bucket teethfeature longer service life.
The hydraulic pipe adopts 24° cone and O ring, settling the issue of leakage.Product ParametersDescription
