Perkins Engine Excavator, Eaton Motor, NACHI Travel Motor, 14.7kw Excavator, Stage Three Emission, Good Quality Excavator, Rubber Track, , Zero Tail Excavator
TIDE POWER TECHNOLOGY CO., LIMITED- Type：Crawler Excavator
- Usage：Hydraulic Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.07
Base Info
- Model NO.：TIDE TD20U TD25U TD30U
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Transport Package：PE Foam
- Specification：2-4 TONS
- Trademark：Tide
- Origin：Fujian
- HS Code：84295200
- Production Capacity：1000
Description
DimensionsA- Overall Length 2770mm 2550mm 3550mm 3870mm 4010mm B- Overall Height 1000mm 1500mm 2200mm 2360mm 2360mm C- Overall Width 925mm 870mm 1320mm 1420mm 1540mm D- Track Width 180mm 180mm 250mm 250mm 250mm E- Platform Turning Radius 1330mm 1330mm 730mm 645mm 710mm F- Length of Track 1210mm 1200mm 1650mm 1895mm 1895mm G- Sprocket to Idler Centres 910mm 910mm 210mm 250mm 250mm H- Between Undercarriage and Ground 380mm 380mm 210mm 250mm 250mm I- Between Boom and Ground - - 1320mm 1340mm 1380mm J- Width of Platform 896mm 896mm 970mm 1350mm 1350mm L- Between Platform and Ground 380mm 380mm 480mm 480mm 480mm 20FT Load 4 Sets 4 Sets 4/2 Sets 2 Sets 2 Sets 40GP Load 8 Sets 8 Sets 8/4 Sets 4 Sets 4 Sets Performance Engine Model KOOP PERKINS 403D-11 Power 8.6kW 14.7kW/2200Rmp Operation Pressure 16Mpa 16Mpa 18Mpa 21Mpa 21Mpa Max. Digging Force 7.2KN 7.2KN 12KN 17.6KN 18.2KN Gradeability 30° 30° 30° 30° 30° Ground Pressure 32Kpa 32Kpa 32Kpa 26Kpa 26Kpa Travel Speed 2Km/h 2Km/h 2.7Km/h 2.3-4.1Km/h 2.3-4.1Km/h Pump Flow Rate 21.6L/min 21.6L/min 2*17.6+6.6L/min 28L/min 28L/min Platform Swing Speed 12rpm 12rpm 13rpm 13rpm 13rpm Bucket Capacity 0.028m³ 0.06m³ 0.07m³ 0.08m³ 0.09m³ Bucket Width 410mm 410mm 450mm 500mm 550mm Boom Swing - - 45°Left/78° Right Overall Weight 800Kg 800Kg 1930Kg 2450Kg 2650Kg Operating Dimensions A- Max. Digging Height 2650mm 2650mm 3300/3825mm 3744/4335mm 3865/4510mm B- Max. Dumping Height 1850mm 1850mm 2360mm 2670mm 2760mm C- Max. Digging Depth 1650mm 1650mm 2200/2405mm 2200/2486mm 2580/2710mm D- Max. Digging Radius 2900mm 2900mm 3975mm 4155mm 4375mm
