• Model NO.：T140-1
• Condition：New
• Color：Yellow
• Machine Weight：17500kg
• Dimension(Long * Breadth * High)：5037×3297×3077mm (Without Ripper)
• Engine：C6121 Diesel Engine
• Transport Package：Nude, Suitable for Shiping
• Specification：ISO
• Trademark：HBXG
• Origin：Hebei, China
• HS Code：84291190
• Production Capacity：1000sets,Month

Basic Info.

Model NO. T140-1 Condition New Color Yellow Machine Weight 17500kg Dimension(Long * Breadth * High) 5037×3297×3077mm (Without Ripper) Engine C6121 Diesel Engine Transport Package Nude, Suitable for Shiping Specification ISO Trademark HBXG Origin Hebei, China HS Code 84291190 Production Capacity 1000sets/Month

Product Description

Specifications

HBXG small crawler bulldozer track shoe for bulldozer T140-1
bulldozer idler
bulldozer track shoe
track shoe for bulldozer



HBXG small crawler bulldozer track shoe for bulldozer T140-1

Dozer                                                                                Tilt
(not including ripper) Operation weight (Kg)                                             16500
Ground pressure(KPa)                                                                  65
Track gauge(mm)                                                                    1880
Gradient                                              30°/25°
Min. ground clearance (mm)                            400
Dozing capacity (m³)                                                                    4.5
Blade width (mm)                                        3297
Max. digging depth (mm)                              320
Overall dimensions (mm)                                                   5486×3762×2842
Engine
Type                                                                      WD10G156E16
Rated revolution (rpm)                                                                1850
Flywheel power (KW/HP)                                                            104/140
Max. torque (N?m/rpm)                                                            830/1100
Rated fuel consumption(g/KW?h)                                                       ≤218
Undercarriage system
Type                                                          Swing type of sprayed beam.
                                                        Suspended structure of equalizer bar
Number of track rollers (each side)                                                         6
Number of carrier rollers (each side)                                                       2
Pitch (mm)                                                                           203
Width of shoe (mm)                                                                    500
