China Top Brand Xe80c Mini Small Crawler Excavator Digger for Sale
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：Provide
- Warranty：1 Year
- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：6-9t
- Transmission：Hydraulic
Base Info
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Small Loader
- Transport Package：Sea
- Origin：China
Description
Overview
Contact Informationmodel unit XE80C Operating weight Kg 7460 Bucket capacity m³ 0.3 engine engine model / 4JG1TPC Direct injection / √ 4-stroke / √ Water cooling / √ Turbocharged / √ Number of cylinders / 4 Engine output power kw/rpm 53.8/2150 Maximum torque/speed Nm 255/1800 Displacement L 3.059 Main performance Walking speed km/h 4.4/2.4 Swing speed r/min 11 Gradeability ° 35° Ground pressure kPa 33.5 Bucket digging force kN 51.2 Stick digging force kN 34.2 main traction force kN 68.5 Rated flow of main pump L/min 172 Main relief valve pressure MPa 27.4 Walking system pressure MPa 27.4 Rotary system pressure MPa 20.6 Pilot system pressure MPa 3.5 Oil capacity Fuel tank volume L 130 Hydraulic oil tank volume L 115 Engine oil capacity L 9.7 Dimensions Total length mm 6144 Total width mm 2272 Total height mm 2682 Turntable width mm 2250 Overall width of chassis mm 2200 Track width mm 450 Wheelbase mm 2195 gauge mm 1750 Counterweight ground clearance mm 797 Minimum ground clearance mm 393 Dozer blade (width/height) mm 2200×396 The scope of work Maximum digging height mm 7135 Maximum unloading height mm 5030 Maximum digging depth mm 4160 Maximum vertical digging depth mm 3485 Maximum digging radius mm 6295 Minimum radius of gyration mm 1800 Minimum gyration radius of tail mm 1805 The maximum lifting height of the bulldozer mm 363 Dozer blade maximum digging depth mm 346 Standard Boom length mm 3720 Stick length mm 1622 Dou Rong m³ 0.3
