• Model NO.：BMSW 315
• Specification：cast iron
• Trademark：hanjiu
• Origin：China
• HS Code：841229100
• Production Capacity：500000

TypeBMSW
80BMSW
100BMSW
125BMSW
165BMSW
200BMSW
250BMSW
315BMSW
400Displacement.(ml/r)80.5100.5126.3160.8200.9252.6321.5401.9Max.Pressure.
Drop (Mpa)cont.17.517.517.5161612.512.510int.2020202020161614peak.22.522.522.522.522.5202017.5Max.torque (Nm)cont.194242303358438440551560int.218283345429540580625687peak.271318373459576700831865Speed. Range (cont.)(r/min)10-81010-7509-6007-4706-3756-3005-2405-180Max.Flow (cont.)(L/min)6575757575757575Max.Output.Power (cont.)(KW)141616141411108Weight (kg)9.810.010.310.711.111.612.313.1










Application

Hydraulic Wheel Motor BMSW Series used for

1. Hydraulic drive systems of mine construction machinery

2. Transporting equipment

3. Agricultural and forest machinery

4. Special vehicles

5. Wheel traveling equipment

6. Driving tracks of rotating mechanisms

Shijiazhuang Hanjiu Technology Co., Ltd. is a professional manufacturer of BM series cycloidal hydraulic motors and BZZ steering gears. Our factory has dozens of highly qualified and professional engineers and technicians, and introduced many advanced machines in 2010. The production facilities are large-scale factories in northern China and produce more than 300,000 units each year.
  Our factory specializes in designing and producing any type of motor and steering gear required by our customers, from large to small, from low to high displacement. And can replace Danfoss, Eaton, M + S series models. Products are widely used in engineering machinery, mining machinery, metallurgical machinery, petroleum machinery, agricultural machinery, injection molding machinery, fishery machinery and other fields.
  My factory takes honesty first and quality first as its tenet. From the employees' posts to the raw materials, to the factory, from parts processing and assembly advice to product leaving, there is a relatively complete product quality system. And passed CE certification. Our factory is committed to establishing an internationally renowned brand and looks forward to long-term cooperation with more demanders of hydraulic products.




Please do not hesitate to contact us for further information, inquiries or orders.
Thank you for choosing 'Hanjiu' Hydraulics.
