• Model NO.：CB25. CB40, CB50, CB65, CB80, CB90, CB100, CB130.
• Technology：Vacuum Brazing
• Hardness：63HRC,700bhn
• Micro-Structure：Carbide+Mantensite+Retained Austenite
• Transport Package：Oli Film, Poly-Wood Crate, Pallets
• Specification：High Grade
• Trademark：HYSTER, DOMITE, OEM
• Origin：China
• HS Code：84314991
• Production Capacity：100tons,Month

Basic Info.

Model NO. CB25. CB40, CB50, CB65, CB80, CB90, CB100, CB130. Technology Vacuum Brazing Hardness 63HRC/700bhn Micro-Structure Carbide+Mantensite+Retained Austenite Transport Package Oli Film, Poly-Wood Crate, Pallets Specification High Grade Trademark HYSTER, DOMITE, OEM Origin China HS Code 84314991 Production Capacity 100tons/Month

Product Description

 White Iron chocky bars

Chocky bar(notched or non-notched)
Chocky Bars are easy to use and install. They can be bent, cut and formed to suit different surfaces.

The unique, formable design of Hyster-Wear chocky bars are available in various lengths, grades and sizes and can also be customized as per the clients specific need. Applications for Chocky Bars are wide and varied, ranging from specific wear protection on buckets for loaders, excavators and draglines machines, or for weld-on hammer tips for the re-cycling industry, or chute linings and rock box edges.


Item No.	Size(mm)	N.W.(kg)
CB25	240X25X23	0.9
CB40	240X40X23	1.5
CB50	240X50X23	1.9
CB65	240X65X23	2.5
CB80	240X80X23	3.2
CB90	240X90X23	3.5
CB100	240X100X23	3.9
CB130	240X130X23	5.4
CB150	240X150X23	7.3

Material:
Wear portion is white iron(high chrome carbide). ASTM 532 15/3CrMo.
Impact portion is mild steel.

Chemical:
C Cr Mn Mo
2.5-3.5 15-18 0.5-1.0 0.5-2.5
Cu P Si S B. V. Nb
0.5-1.0 0.02max 0.5-1.0 0.02max 0.1-0.5

Mechanical Property:
1) Tensile Strength 630Mpa Min.
2) Shearing Strength 250Mpa Min.
3) Hardness 63 HRC

 Hyster offer our clients a wide range of wear products and professional wear solutions. We also welcome custom made one off's and consumables.

Following are our laminated wear blocks:
Laminated wear blocks---the most common types are:
  1) Chocky bars (CB 25. CB40, CB50, CB65, CB80, CB90, CB100, CB130. CB150)
  2) Standard wear bars (DLP201A, DLP 125, DLP184, DLP528, DLP619, DLP451, DLP450, DLP2230, DLP2017, DLP4, DLP919, DLP1191, DLP515, DLP200, DLP271, DLP270, DLP508, DLP115, DLP337, DLP1101, DLP343 )
  3) Shaped wear bars
  4) Wear buttons& donuts(WB60, WB75, WB90, WB110, WB115, WB150, DLP1920, DLP1921, DLP1994, DLP2196)
  5) Shredder/Grinder hammer tips (DLP1654,90X90X50mm; DLP653,90X90X45mm; DLP1927, 90X90X55mm)
  6) Bi-metallic wear plates
  7) Knife edges(DLP1065-22, 203X22X50MM; DLP1265-22,305X22X50MM; DLP1065A-16, 203x16x50mm, DLP1065A-25, 203x25x62mm; DLP1265A-25, 305x25x56mm)
  8) Skid bars, skid blocks(DLP412, 250x150x45mm; DLP413, 200x150x45mm; DLP414, 250x250x45mm)
  9) Wafer strips, WS25, WS40, WS50, WS65;
 10) Elbow wear blocks
 11) Other sizes and shapes
 12) Multi-function gradient cutter tooth
 13) Rockbox liners
 14) Micro-ledges
Overlay wear plates: standard sheet size 1500x3000mm, thickness 4+4(8mm), 6+4(10mm), 6+6(12mm), 8+5(13mm), 8+6(14mm), 10+5(15mm), 10+10(20mm), 12+12(24mm), 12+17(29mm).

Some of our products and services:
  --Wear plates, wear liners
  --Chocky bars and wear buttons
  --Wear blocks, wear bars
  --Custom made wear liners
  --Bucket repair and protection
  --Full Fabrication services
  --Sugar mill hammer tips
  --Drilling, milling or machining
  --Casting/Investment casting
  --Fast service and timely delivery
