Cheap 3 Ton Mini Wheel Loader Xgma Xg935h with High Quality
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic
Base Info
- Model NO.：XG935H
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Transport Package：Main Machine Nude, Attached Parts and Tools Into S
- Specification：8110*25000*3450mm
- Trademark：xgma
- Origin：China
Description
Manufacturer
XGMA
Model
XG935H
Overall length(mm)
6970
Overall height(mm)
3330
Overall width(mm)
2245
Wheel base(mm)
2750
Ground clearance(mm)
356
Tread(mm)
1800
Bucket Width (mm)
2420
Turn radius(mm)
5280
Min.Turn radius outside of bucket (mm)
5860
3930
Max. Dumping Height(mm)
3060
Dumping Reach(mm)
1020
Digging depth(mm)
100
50
Engine model
YC6J125Z-T20
Rated power (kw)
92
Fuel comsumption per hour(g/kw.h )
225
Rated speed (r/min)
2200
Max torque(N.m)
500
Operating Weight (Tonnes)
10.8
Rated Load(Tonnes)
3.2
Bucket capacity (m3)
1.4-3.0
Lifting time/Lifting, dumping and lowering(s)
6/10.4
Max Breakout force(KN)
100
Max.drawing force (KN)
103
Max. turning angle(°)
±35°
Climbing ability(°)
≤ 30 °
Fuel tank(L)
140
Hydraulic tank(L)
160
Working pressure of steering hydraulic system(MPa)
13
Working pressure of load hydraulic system(MPa)
16
Travel speeds(km/h)
FORWARD 1ST
0~12
FORWARD 2ND
0~40
FORWARD 3RD
FORWARD 4TH
REVERSE 1ST
0~16
REVERSE 2ND
