New Wa380 Wheel Loader Front End Loader Payloader Construction Mining Equipment Price
Evangel Industrial (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：WA380
- Type：Medium-sized Loader
- Product Name：Construction Equipment
- Export：Front End Loader Export to Over 100 Countries
- Operating Weight：16620kg
- Transport Package：Stand Export Package
- Trademark：EV
- Origin：China
- Production Capacity：1000units,Month
Description
Basic Info.
Model NO. WA380 Type Medium-sized Loader Product Name Construction Equipment Export Front End Loader Export to Over 100 Countries Operating Weight 16620kg Transport Package Stand Export Package Trademark EV Origin China Production Capacity 1000units/MonthProduct Description
Supply New Wheel Loader:WA100, WA230, WA250, WA300, WA320, WA350, WA360, WA380, WA400, WA430, WA470
The WA380 is well suited for construction sites, agricultural and utility work. With excellent break out force, tipping loads and serviceability, the WA380 helps get the job done. The engine with enhanced controller logic helps to improve performance and fuel efficiency.
The comfortable and quiet cab includes a new, more robust, heated air suspension seat with seat-mounted controls for improved operator comfort. Like other loaders, the 7 inch LCD color monitor allows the operator to easily keep an eye on key machine parameters. The dedicated color rear view monitor helps the operator get a better picture of the machine's surroundings.
Service items are consolidated and accessible from ground level, making daily inspections easier. An adjustable auto-reversing fan helps keep the coolers clean in almost any application. Swing out engine doors, and a swing out cooling fan make inspections, cleaning and maintenance quick and easy.
WA380
| Drive system | Four-wheel drive |
| Front | Fixed, semi-floating |
| Rear | Center-pin support, semi-floating, 26° total oscillation |
| Reduction gear | Spiral bevel gear |
| Differential gear | Conventional type |
| Final reduction gear | Planetary gear, single reduction |
WA380
| Model | ||
| Type | Water-cooled, 4-cycle | |
| Aspiration | Turbo-charged, after-cooled | |
| Number of cylinders | 6 | |
| Bore x Stroke | 107 mm x 124 mm | 4.21" x 4.88" |
| Piston displacement | 6.69 ltr | 408 in3 |
| Govenor | All-speed, electronic | |
| HORSEPOWER: | ||
| SAE J1995 - Gross | 143 kW | 192 HP |
| ISO 9249 / SAE J1349 - Net | 143 kW | 191 HP |
| Rated rpm | 2100 rpm | |
| Fan drive method for radiator cooling | Hydraulic | |
| Fuel system | Direct injection | |
| LUBRICATION SYSTEM: | ||
| Method | Gear pump, force-lubrication | |
| Filter | Full-flow type | |
| Air cleaner | Dry type with double elements and dust evacuator, plus dust indicator |
| Working weight (kg) | 16620 | Maximum traction force (KN) | 95.4 |
| maximum excavation force (kN) | 168 | The maximum steering Angle | 40 |
| Rated power KW (HP) | 142 | Total length (mm) | 7715 |
| Total width (mm) | 2780 | Total height (mm) | 3395 |
| Years | NEW | Walking style | wheeled |
| Bucket capacity (stere) | 3.3 | Engine model | SAA6D107E - 1 |
| Displacement (L) | 6.69 | Cooling | water |
| The fuel tank (L) | 300 | The hydraulic oil tank (L) | 139 |
| Engine oil (L) | 23 | Cooling liquid (L) | 30.5 |
| Drive axle type | four-wheel drive | Drive axle swinging Angle | 80 |
| Lift (s) | 5.9 | Drop(s) | 3.3 |
| Unload(s) | 1.8 | The wheelbase (mm) | 3300 |
