Xcmc Hydraulic 300 Strong Power New Motor Grader Gr300 for Sale

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Application：Railway, Mine, Farmland, Highway
  • Transmission：Hydraulic
  • Walking Mode：Crawler
  • Type：Large Grader

Base Info

  • Model NO.：GR300
  • Rated Power/Speed：224kw,2100rpm
  • Dimension(Lxwxh)：10500×3100×3550mm
  • Operating Weight(Standard)：26000kg
  • Tractive Force：140kn
  • Max. Gradeability：30%
  • Tire Inflation Pressure：350 Kpa
  • Transport Package：Nude
  • Specification：8225x3016x3515
  • Trademark：XCMC
  • Origin：China
  • Production Capacity：350units,Month

Description

Basic specification

Engine modelQSL9Rated power/speed  224kW/2100rpmDimension(LxWxH)10500×3100×3550mmOperating weight(Standard)26000kg

Performance specification

Travelling speed ,forward5,8,11,19,23,40 km/hTravelling speed ,reverse5,11,23 km/hTractive force(f=0.75)140KNMax. gradeability30%Tire inflation pressure350 kPaWorking hydraulic pressure16 MPaTransmission pressure1.3~1.8MPa

Operating specification

Max. steering angle of front wheels±50°Max. lean angle of front wheels±17°Max. oscillation angle of front axle±15°Max. oscillation angle of balance box15Frame articulation angle±27°Min. turning radius using articulation8.0mBiadeMaximum lift above ground450mmMaximum depth of cutting500mmMaximum blade position angle90°Blade cutting angle28°-70°Circle reversing rotation360°Moldboard width X height4920×787mm
