HOWO Asphalt Road Spraying Truck Trailer 4X2 10m3 336HP
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Asphalt Distributor
- Object：Asphalt Concrete Pavement
- Moving Type：Mobile
- Mixing Method：Intermittent Compulsory
- Automatic Grade：Semi-Automatic
- Product Capacity：40～400t,h
Base Info
- Certification：ISO9001: 2000, CE
- Condition：New
- Spraying Medium：Emulsified Asphalt, Hot (Modified) Asphalt, Kerose
- Spraying Width：200-6000mm
- Asphalt Tank Capacity：13000L
- Asphalt Spraying Dosage：0.2~3.0kg,M2
- Spraying Precision：1.5%
- Function：Road Surface Asphalt Spreader
- Paving Speed：0-20 M,Min
- Fuel Tank：400L
- Spray Volume：0.25-4 L,M2
- Asphalt Capacity：14 Ton
- Max Speed：79 Km,H
- Transport Package：Nude
- Trademark：HOWO
- Origin：Shandong, China
- Production Capacity：100units,Week
Description
Chassis model
Sino truck Howo
Cab
Howo single row cab, with power steering. Electronic flameout,without a/c
Driving Type
4*2 Left hand driving
Max Speed (km/h)
99
Overall dimension(mm)
8400*2496*3700
GVW( kg)
16000
Mass in working order ( kg)
9000
Tank Capacity (L)
Wheelbase(mm)
4700
F/R track base (mm)
1900/1800
F/R overhang (mm)
1205/2905
Approach/Departure Angel
25/14
Tire
9.00-20 (6+1)
Clutch
Single-plate dry diaphragm spring clutch
Steering
Hydraulic steering with power assistance
Gear box
6-speed
Bridge
Front axle
6T
Rear axle
10T
Enging
Model
WD615
Fuel Type
Diesel fuel
Type
Water-cooled four-stroke,, direct injection, turbocharged
Exhaust(ml)
Max output power/rotate speed (hp /rpm )
290
Max torque/rotate speed(N.m/rpm)
5900L
Braking system
Service Brake
Compressed air brake
Park Brake
Spring energy
Auxiliary brake
engine exhaust brake
Eletric system
24v
