China Factory Direct Sale Fr18e-U Mini Crawler Excavator with Cheap Price

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • Type：Crawler Excavator
  • Usage：Marine Excavator
  • Bucket：Backhoe
  • Transmission：Hydraulic Transmission
  • Drive Type：Electric Drive
  • Bucket Capacity：1.0~1.5m³

Base Info

  • Model NO.：FR18E-U
  • Size：Small-Scale
  • Certification：CE
  • Condition：New
  • Product Name：Fr18e-U
  • Standard Bucket Capacity (M3)：0.04
  • Rated Power/Rotate Speed (Kw/Rpm)：11.5,2400
  • Transport Dimensionsmm：3575*1050*2347
  • Bucket Digging Force (Kn)：15.2
  • Maximum Traction (Kn)：13.5
  • Maximum Working Speed (Km/H)：3.7
  • Climbing Performance(°)：30
  • Total Length of The Crawler(mm)：1593
  • Minimum Radius of Rotation (mm)：1443
  • Transport Package：Nude
  • Trademark：Famous
  • Origin：China
  • HS Code：84295212
  • Production Capacity：2000

Description

Operation Weight (Standard Configuration) (kg)1810Standard Bucket Capacity (m3)0.04Rated Power/Rotate Speed (KW/rpm)11.5/2400Transport Dimensionsmm3575*1050*2347Bucket Digging Force (KN)15.2Bucket Rob Digging Force (KN) Maximum Traction (KN)13.5DeviceMaximum Working Speed (Km/h)3.7Climbing Performance(°)30Total Length of the Crawler(mm)1593Minimum Radius of rotation (mm)1443Width of the Crawler(mm)230Ground Pressure (Kpa) Turning Mechanism Turning Speed (rpm)9EngineModelYANMA 3TNV70 PFNTypeThree Cylinders,China's Stage lllRated Torque/Rotate Speed (N.m/rpm)48/1600Cylinder Diameter*Stroke (mm) Output Value (L) Fuel Consumption (g/KW.h) Fuel Tank Capacity (L)19Hydraulic SystemMain Pump Pressure (Mpa)21.6Main Pump Flow(L/min)17.2x2Operating ScopeMaximum Digging Height (mm)3540Maximum Dumping Height (mm)2440Maximum Digging Depth (mm)2310Maximum Digging Radius (mm)3905
