Shan Dong Yinneg Yn918 CE Approved ISO Wheel Loader
Shandong Yineng Heavy Industry Co., Ltd.- Type：Wheel Excavator
- Bucket Capacity：0.7 M3
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Rated Load：1500 Kg
Base Info
- Model NO.：YN918
- Dumping Height：2700 Mm
- Dumping Reach：860 Mm
- Max. Breakout Force：40 Kn
- Max. Drawing Force：32 Kn
- Rated Power：38 Kw,2400 Rpm
- Tire：20.5-16
- Overall Dimensions：5520*1800*2650 Mm
- Operating Weight：4500 Kg
- Transport Package：Naked
- Origin：Taian City, Shandong Province, China
- HS Code：8429510000
- Production Capacity：50PCS,Week
Description
Basic Info.
Model NO. YN918 Dumping Height 2700 Mm Dumping Reach 860 Mm Max. Breakout Force 40 Kn Max. Drawing Force 32 Kn Rated Power 38 Kw/2400 Rpm Tire 20.5-16 Overall Dimensions 5520*1800*2650 Mm Operating Weight 4500 Kg Transport Package Naked Origin Taian City, Shandong Province, China HS Code 8429510000 Production Capacity 50PCS/WeekProduct Description
0.7 m3, 1.5 ton front wheel loader, with ISO901: 2000 CE approved.* Adopt Jiangsu Changchai 4L68 Diesel Engine.
* Hydrodynamic transmission technology and separated structure make high reliability and easy maintenance.
* Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operate easy.
* Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
* Double sealed hydraulic pipeline joints with 24° Awl and O ring of international standard, avoiding oil leakage;
* Load sensing fully hydraulic steering system makes operation easy.
* Air over hydraulic brake system; Caliper disc brakes.
* Working device with automatically levelling ability at high position.
* Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin.
OPTIONAL:
(1) Xinchai 498BTT(EUROIII/43KW)
(2) A/C
(3) Joystick control
(4) Quick Hitch
(5) Fork
(6) ROPS
| Item | Specifications | Item | Specifications |
| Bucket capacity | 0.7 m 3 | Min. turning radius (outside of rear wheel) | 4200 mm |
| Rated load | 1500 kg | Steering angle | 35º (L/R) |
| Dumping height | 2700 mm | Min. ground clearance | 250 mm |
| Dumping reach | 860 mm | Wheel base | 2150 mm |
| Boom lifting time | 4.5 S | Tread | 1400 mm |
| Total cycling time | 9 S | Engine model | Changchai 4L68 |
| Max. speed | 19 km/h | Rated power | 38 kW/2400 rpm |
| Max. breakout force | 40 kN | Tire | 20.5-16 |
| Max. drawing force | 32 kN | Overall dimensions | 5520*1800*2650 mm |
| Max. Grade ability | 28° | Operating weight | 4500kg |
