| YN706 Technical Parameters |
| Engine / Motor | |
| Engine / Motor manufacturer | Perkins |
| Engine / Motor type | 403D-11 |
| Engine performance | 18.5 kW |
| at rpm maximum | 2,800 rpm |
| Displacement | 1,131 cm³ |
| Operating data and Weights | |
| Operating weight | 1560kg |
| Speed Level 1 | 0-12 km/h |
| Bucket capacity Standard bucket | 0.25m³ |
| Lifting force maximum | 1,981 daN |
| Breakaway force maximum | 1,242 daN |
| Tipping load with bucket - machine straight | 850 kg |
| Tipping load with pallet fork -machine straight | 690 kg |
| Tipping load with bucket - machine at angle | 580 kg |
| Tipping load with pallet fork - machine at angle | 540 kg |
| Hydraulic system | |
| Driving hydraulics - operating pressure | 300bar |
| Driving hydraulics - discharge capacity | 84 L/min |
| Operating hydraulics - operating pressure | 185 bar |
| Operating hydraulics - discharge capacity | 33 L/min |
| Filling capacities | |
| Tank capacity (fuel) | 25 L |
| Engine oil | 4 L |
| Hydraulic oil tank | 40 L |
| Coolant | 4.3L |
| Front axle | 2.5L |
| Rear axle | 2.5L |
| Electrical system | |
| Operating voltage | 12 V |
| Battery | 45Ah |
| Alternator | 60 A |
| Tire | |
| Type as standard | 27×8.5-15 |
| Type as option | 26*12.00-12 |
