XCMG Official Gr1605 170HP Motor Grader China Motor Grader with The Best Price
XCMG E-Commerce Inc.- Certification：Ce,ISO9001
- Condition：New
- Hydraulic Cylinder Brand：Undetermined
- Warranty：1 Year
- Working System Pressure：20MPa
- Reverse Speed(Km/H)：30
Base Info
- Model NO.：GR1605
- Tire Inflation Pressure：300kpa
- Applicable Industries：Hotels, Garment Shops, Building Material Shops
- Dimension(L*W*H)：8711*2473*3385mm
- Hydraulic Valve Brand：Undetermined
- After-Sales Service Provided：Overseas Service Center Available
- Hydraulic Pump Brand：Undetermined
- Forward Speed(Km/H)：47
- Engine Brand：Undetermined
- Transport Package：Comply with Export Packaging Requirements
- Trademark：XCMG
- Origin：Jiangsu, China
- Production Capacity：10000 Unit,Units Per Year
Description
ItemGR1605 Basic parameters Engine model QSB5.9 Rated power/speed 125kW/2200rpm Overall dimension (standard) 8711x2483x3385 Total weight (standard) 12500 kg Tire specification 14.00-24 Ground clearance (front axle) 586mm Tread 2113mm Space of front and rear axles 6279 mm Space of middle and rear wheels 1568 mm Performance parameter Forward velocity 5,8,13,18,30,47km/h Reverse speed 5,13,30km/h Tractive effort f=0.75 ≥70 kN Maximum gradeability ≥25% Tire inflation pressure 260kPa Working system pressure 22MPa Transmission pressure 1.3-1.8Mpa Maximum steering angle of front wheel ±48° Maximum slant angle of front wheel ±18° Maximum oscillating angle of front axle ±16° Maximum oscillating angle of equilibrium box ±15° Maximum steering angle of frame ±20° Minimum turning radius 7.2m blade Maximum lift height 410mm Maximum cutting depth 715mm Maximum tilt angle 90° Cutting angle 29°-69° Angle of revolution 360° Length & chord height 3965x610mm Oil filling amount Coolant 50L Fuel tank 380L Engine 24L Transmission 38L Equilibrium box 60L Coolant 36L Hydraulic oil 170L
