• Model NO.：gr180
• Forward Speed(Km/H)：38
• Transport Package：Comply with Export Packaging Requirements
• Trademark：XCMG
• Origin：Jiangsu, China
• Production Capacity：10000 Unit,Units Per Year

ItemGR180Basic parametersEngine model6CTA8.3-C190-Rated power/speed142kW/2200rpmOverall dimension (standard)8900x2625x3420Total weight (standard)15400 kgTire specification17.5-25Ground clearance (front axle)430mmTread2156mmSpace of front and rear axles6219 mmSpace of middle and rear wheels1538 mmPerformance parametersForward velocity5 8 11 19 23 38km/hReverse speed5 11 23km/hTractive effort f=0.75≥79 kNMaximum gradeability≥25%Tire inflation pressure260kPaWorking system pressure18MPaTransmission pressure1.3-1.8MpaWorking parametersMaximum steering angle of front wheel±50°Maximum slant angle of front wheel±17°Maximum oscillating angle of front axle±15°Maximum oscillating angle of equilibrium box±15°Maximum steering angle of frame±27°Minimum turning radius7.3mScrape knifeMaximum lift height450mmMaximum cutting depth500mmMaximum tilt angle90°Cutting angle28°-70°Angle of revolution360°Length & chord height3965x610mmOil filling amountCoolant50LFuel tank280LEngine24LTransmission38LBalancing box46LDrive axle28LProduct Show  Related Products To Choose Online Service Team Company Profile
