Pz-3 Schneider Electric Control System Concrte Spraying Machine

Eternoo Machinery Co., Ltd.
  • Type：Shotcrete
  • Shotcrete Type：Dry
  • Machining Process：Spraying Concrete
  • Structure：Rotor Type
  • Productivity：3m3,H
  • Feeding Height：1400mm

Base Info

  • Model NO.：PZ-3
  • Vibrating Amplitude：2.6mm
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Yellow
  • Original：China
  • Warranty：1 Year
  • Delivery Time：in Stock or 10 Days
  • Voltage：220V, 380V, 400V,440V, 50,60Hz
  • Transport Package：Wooden Case
  • Trademark：ETERNOO

Description

pz-3 shotcrete machine with air motorOutput Capacity:3 m3/hour Maximum Conveying Distance:200 m(660 ft),horizontal; 70m,verticalDesired Shotcrete Ingredient Ratio:Cement/sand and gravel  < 0.35Maximum Aggregate Size:10 mm(2/5" )Inner Diameter of Conveying Hose:51 mm(2" ) or 42mm (1 5 /8" )Working Compressed Air Pressure:29 ~ 87 psi (0.2 ~ 0.6 MPa)Conveying Air Consumption:175 ~ 210 cfm (5 ~ 6 cubic meter / min)Air Motor Power:3.2kW Dimensions:1130 x 450 x 1020 mmNet Weight:430 Kg
