• Model NO.：XE470C
• Size：Large-Scale
• Certification：CE
• Condition：New
• Operating Weight：46100kg
• Engine Model：Cummins Qsm11
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：xcmg
• Origin：Xuzhou, Jiangsu, China
• HS Code：87059091
• Production Capacity：10000,Year

  UnitParametersModelOperating weightkg46100Bucket capacitym³2.1-2.5EngineEngine model/Cummins QSM11Direct injection/√4×Strokes/√Water cooling/√Turbocharging/√A/A Air-air intercool/√Cylinders/6Output power of engineKw/rpm250/2000Max.torque/engineN.m/rpm1790/1400DisplacementL11Mian pertormanceTravel speedkm/h5.4/3.2Slewing speedr/min9Gradient capability°≤30°Ground pressurekPa82.7Digging capacity of tcuketkN284Digging capacity of tcuket rodkN236Max.tractionkN338Hydraulic systemMain pump/Tow plunger pumpsRated flow of main pumpL/min2×360Pressure of main safety valveMpa31.4/34.3Pressure of traveling systemMpa34.3Pressure of swing systemMpa28.4Pressure of pilot systemMpa3.9Oil volumeFuel tank capacityL650Hydraulic tank capacityL360Engine oil volumL38Apperance sizeA Total lengthmm12032B Total widthmm3580C Total heigthmm3842D Width of rotary tablemm2950E Length of trackmm5220F Total width of chassismm3580G Width of trackmm600H Wheelbase of trackmm4180I Track gaugemm2392/2890J Counterweight ground clearancemm1360K Min.ground clearancemm703(Tooth height not included)L Min.tail swing radiusmm3665Working scopeA Max.digging heightmm10675B Max.unloading heightmm7409C Max.digging depthmm7337D Digging depth at the range of 8feets horizontallymm7177E Max.vertical digging depthmm5225F Max.digging radiusmm11631G Max.swing heightmm4909Standard configurationBoom lengthmm7060Length of bucket rodmm2900Bucket capacitym³2.2Rock bucketOptional counfigurationBoom lengthmm7060Length of bucket rodmm3380/2500Bucket capacitym³2.1  2.3Rock bucket   2.5Earthmoving bucket
Company profile
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2015, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.

At present, the power of my company's straight-arm crane is entirely from the hydraulic oil pressure, that is, through the high-pressure hydraulic oil to promote the cylinder piston reciprocating motion, or drive the hydraulic motor rotation makes the hydraulic winch and rotary mechanism rotation.

So, how do high-pressure hydraulic oil get? Each truck crane is equipped with a hydraulic pump when the vehicle chassis is matched, and the engine provides power for it. The chemical energy of the fuel can be converted into the crankshaft of the engine to rotate the mechanical energy, and then the gearbox gear is rotated, and then the power is transmitted to the hydraulic pump through the power transmission of the gearbox. Therefore, the hydraulic pump can continuously pressurize the hydraulic oil For the high-pressure hydraulic oil, so as to provide power for the crane to achieve the lifting of the goods.
