MastMaximum extention of mast 9mElevationMechanical/ElectricRaising/lowing mastWinch(Mechanical)/Button(Electric)Stages3Turning angle358 degrees non-continuousLampTotal power of lamps4X1000WType of lampMetal halide lampLight capacity4×88,000 lumen Voltage120,220,230,240Frequency50Hz/60HzLifetime of lamp5000 hoursWorking temperature≤85ºCConnection Protection indexIP54Light Coverage5 to 7 acresCharacteristics of the generator  ModelRD20CGenerator set Prime power50Hz  20kW   60Hz 23kW       Standby power50Hz  22kW   60Hz 25kW       Engine modelCummins 4B3.9-G1 DieselEngine speed50Hz 1500rpm / 60Hz 1800rpmEngine type41 cylinder,in line,water-cooledEngine AspirationTurbo chargedAlternator Type4-pole, brushlessFuel tank capacity 70LPrime fuel consumption at 100% load5.6L/hWorking hours12Control systemT210 Digital control panelPower Outlets3Trailer  Tow hitchRing or ball hitchStabilier Supports5 × ManualTire Size70cmAnti-wind capacity≤10BrakesManualPacking Dimension & WeightRetracted  Dimension 4400mm × 1450mm × 2100mm
