Cheapest Pile Driver Machine Hammer Pile Driver Jdy 920b Pile Driver
Shandong Davoo Machinery Co., Ltd.- After-sales Service：Interview,Video Show
- Warranty：6 Month
- Type：Pressure Pile Driver
- Pressure Pile Driver Type：Mechanical Pile Driver
- Pile Hammer Type：Steam Hammer
- Power Source：Diesel
Base Info
- Model NO.：JDY 920B
- Motor Power：11kw
- Noise：With Noise
- Certification：ISO 9001:2000
- Condition：New
- Model No：920b
- Weight：4600kg
- Engine Model：Yn490
- Rated Power：42kw
- Pumps：Double Pumps
- Brakes：Double Oil Brake
- Chassis：Speical for Pile Driver
- Gear Box：Hydraulic
- Drive Model：Four Wheel Drive
- Pile Length：3000mm
- Pile Model：Round&Square
- Pile Size：80-300
- Hammer：75*
- Piling Rig：Optional
- Piling Set：Optrional
- Transport Package：Naked
- Specification：4000*2700*2800MM
- Trademark：JDY
- Origin：Shandong, China
- HS Code：8430100000
- Production Capacity：100pieces Per Week
Description
920B Product parametersMODEL NUMBER 920B MACHINE WEIGHT 4600KG RATED POWER 37KW COOLING SYSTEM DOUBLE FAN COOLING ENGINE MODEL YN 490 BRAKE MODE DOUBLE BREAK AIR BRAKE SPINDLE SPEED 2400R / S DRIVER MODE FOUR-WHEEL DRIVE MAX WALKING SPEED 30-35KM / MINUTE TYRE SIZE FOUR WHEELS20.5-16 MAIN PUMP DOUBLE OIL PUMP WALKING MODE AUTOMATIC GEAR CHASSIS PILING MACHINE CHASSIS OVERALL SIZE 390* 265*300CM PILE TYPE ROUND& SQUARE PILE LENGTH 3000MM PILING SPEED 8~10M/M PILE SIZE φ 80-180MM PILING RIG OPTIONAL AIR COMPRESSOR 3.5M3 /5M3 HAMMER HAMMER TYPE Hydraulic SB43(75#)
HAMMER WEIGHT 194KG Hammer Impact frequency
400-800 TIME/MIN Working Flew of Hammer 50-90L/MIN Working Pressure Of Hammer
12-14MPA
