Item | Parameter | Unit |
Rated load | 5 | t |
Bucket capacity | 3 | m3 |
Dumping height | 3090 | mm |
Dumping distance | 1130 | mm |
Max.drawing force | 170 | kN |
Max. traction | 165 | kN |
Dimension | 8185*3000*3465 | mm |
Operating weight | 17200 | kg |
Boom lifting time | <6.0 | <6.0 |
Total time of three devices | 11 | s |
Wheelbase | 3300 | s |
Min. turning radius (bucket outer) | 6910 | mm |
Rated power | 162 | kW |
Travel speed | I Gear (Forward/Backward) | 0-11.5/16.5 | km/h |
II Gear (Forward) | 0-38 | km/h |
Long boom parameter |
Item | Standard bucket | Coal bucket |
Bucket capacity | 2.7m³ | 3.5 |
Rated load | 4.5t | 4.0t |
Dumping height | 3710mm | 3550mm |
Dumping distance | 1180mm | 1300mm |
Dimension | 8870*3000*3350 | 8870*3000*3465 |
Attachment parameter |
Attachment parameter_snow plow |
Pushing snow width | 3800 | mm |
Horizontal rotary angle | 38 | ' |
Vibrating angle | 6 | ' |
Obstacle crossing height | 0~150 | mm |
Rated power | 162 | KW |
Attachment parameter-clamp |
Dumping height | 3241 | |
Dumping distance | 1902 | |
Min. circle diameter and max. opening | | |
Basic model | ¢800*1990 | |
IV model | ¢430*2000 | |
Attachment parameter-Sliding fork |
Fork folding angle | 20 | ' |
Attachment length | 2053 | mm |
Attachment width | 2516 | mm |
Attachment height | 1200 | mm |
Fork teeth length | 1200 | mm |
Attachment parameter-Side dumping |
Bucket width | 3000 | mm |
Dimension | 8310*3040*3465 | mm |
Dumping height(straight/side) dumping | 2960/4125 | mm |
Dumping distance(straight/side) dumping | 1272/105 | mm |
Lifting height(straight/side) dumping | 5407/6830 | mm |
