• Model NO.：YC15-8
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.5~1.0m³
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Specification：5690*2070*3590mm
• Trademark：YUCHAI
• Origin：China

Excavator ModelYC08-9YC15-8YC18-9Basic parameter      Machine weight 1030kg1625kg (Canopy)
1725kg (Cabin)1700kg(Canopy)
1850kg(Cabin)Bucket capacity 0.02m³0.04m30.05m³Width of bucket 350mm400mm469mmPerformance parameter     Engine model  Max. digging height2737mm2940mm2940mmMax. digging depth1415mm1810mm1895mmMax. digging radius2829mm3570mm3645mmMax. digging radius on ground level 2726mm3460mm3540mmMax. dumping height 1951mm2040mm1955mmMin. slewing radius 1248mm1700mm1720mmMax. vertical digging depth956mm1210mm1225mmTransportation dimension     Overall length2800mm3600mm3595mmOverall width930-1130mm1000-1300mm990mmOverall height 2300mm2245mm(with Canopy)
2310mm(with Cabin)2275mm(with Canopy)
2340mm(with Cabin)Other Parameter     Width of undercarriage 930-1130mm1000-1300mm1000-1300mmLength of track1234mm1405mm1585mmWidth of track 180mm230mm230mmHeight between undercarriage and ground 155mm190mm180mmHeight between platform and ground 422mm414/453mm ext.chassis460mmPlatform tail turning radius 702mm1175mm1140mmTrack gauge895mm1045mm760mmFuel tank capacity 10L21L20LHydraulic oil tank capacity 7.5L32L22L      Type and flow rate of pumpConstant Flow Pump
2*9.9 L/min
