• Model NO.：DH17-B2
• Engine Power：74~147kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Transport Package：by Sea,Air,Train
• Specification：Dimension: 5250*3420*3080mm
• Trademark：SHANTUI
• Origin：China
• HS Code：84291190
• Production Capacity：500,Month

Parameter nameDH17 B2 XLDH17 B2 LGPPerformance parameters  Operating weight (Kg)17500(Ripper not included)19360Ground pressure (kPa)6430Engine  Engine modelWD10G190E214WD10G190E214Rated power/rated speed (kW/rpm)140/1900140/1900Overall dimensions  Overall dimensions of machine (mm)5250*3420*30805340*4150*3091Driving performance  Forward speed (km/h)0~100~10Reversing speed (km/h)0~100~10Chassis System  Center distance of track (mm)18802350Width of track shoes (mm)510/560/6101100/950Ground length(mm)26752935Tank capacity  Fuel tank (L)305305Working device  Blade typeSemi-U/Straight-tiltStraight-tiltDigging depth (mm)520485Ripper type3 shank-Ripping depth (mm)475-SHANTUI 170hp Hydraulic Crawler Bulldozer DH17-B2
Wei/chai mechanical engine conforms to the China-II non-road machinery emission regulation, featuring high intelligence and
efficiency, simple structure, high parts interchangeability, and low maintenance cost.
The intelligent match technology can achieve best working efficiency and most reasonable fuel economy, with the composite fuel consumption reduced by 10~15%. The double-module (Function and safety) controller architecture verifies with each other to achieve higher safety and
reliability.
The malfunction self-diagnosis function is provided to accurately indicate the malfunction cause and orientation and shorten the downtime.
The service software with distinct access hierarchy features high simpleness and practicability and easy learning and
understanding.The machine adopts double-circuit electronically controlled hydrostatic drive system to ensure good load self-adaptability, loaded and in-situ steering capability, stepless speed regulation, and high flexibility and efficiency and realize outstanding construction performance in narrow sites.
The undercarriage system features long ground length, high ground clearance, stable driving, and excellent trafficability. The standard traction frame and the optional three-shank ripper are provided.
The standard LED working lamps of higher illumination intensity improve the illumination capability during nighttime operations to achieve higher safety and reliability.
