• Model NO.：381-101.6-42
• Links：42
• Warranty：12 Months
• Color：Black
• Weigth：80kg,Piece
• Transport Package：Wooden Pallet or Can Be Customized
• Specification：381-101.6-42,382-102-42
• Trademark：PY
• Origin：Shanghai
• HS Code：843149900
• Production Capacity：5000 Pieces,Month

Basic Info.

Model NO. 381-101.6-42 Links 42 Warranty 12 Months Color Black Weigth 80kg/Piece Transport Package Wooden Pallet or Can Be Customized Specification 381-101.6-42/382-102-42 Trademark PY Origin Shanghai HS Code 843149900 Production Capacity 5000 Pieces/Month

Product Description

Product Information:

The characteristics of rubber tracks
1.Rubber tracks cause less damage to roads than steel tracks, and less rutting on soft ground than steel tracks
2.A benefit to equipment operating in congested areas, rubber tracks make less noise than steel tracks
3.Rubber tracks permit machines to travel at a higher speed than steel tracks
4.Rubber tracks insulated machine and operator from vibraion, extedin the service life of machine and decreasing operator's fatigue
5.The ground pressure of rubbr tracks equipped machinery can be fairly low, about 0.14-2.30 kg/m2, a major reason for its use on wet and soft terrain.
6. The added traction of rubber tracked vehicles permits them to pull twice the load of wheeled vehicles of the same weight.
7. Rubber tracks' pulling performance being twice that of wheels, it permits the lighter vehicles equip with rubber track to do the same pulling work than that of wheeled vehicles.

The notices of using rubber tracks
Anti-vibration Rubber Track:

The gap between iron cores is very small so that it can support the track roller completely during driving, reduce the shock between machine and rubber trcak, increase the comfortableness for the operators, and extend the life of rubber track and machine.
1. Adjust the tension of the rubber crawler so that the height, the variable range is 10-20mm when the machine is lifted. Readjust when the tension decreases.(Be careful because the rubber crawler may come off  if the tension is too low).
2. Avoid projection from the frame around the rubber crawler, especially on its inner circumference.(Rubber crawlers are easily deformed; if it comes into contact with the frame, an accident such the rubber being cut can occur).
3. Avoid sharp projections when traveling.
4.Avoid turning too fast on concrete roads with a high coefficient of frction because this can cause accidents such as cutting the rubber.
5. Be careful that no oil, etc adheres to the rubber track. If it does, wipe it off immediately.
6. When storing for long periods, keep indoors, away from direct sunshine and rain.
7. Replace as soon as possible when abrasion of sprockets is observed

RUBBER TRACK SIZE WE CAN SUPPLY


SIZE	WEIGHT/link	SIZE	WEIGHT/link	SIZE	WEIGHT/link
130*72	0.36	WD300*72	0.99	400*144	7.75
150*60	0.52	B300*84	2.88	400*144Y	7.41
150*72	0.55	T300*86	3.13	420*100	5.3
170*60	0.48	300*109KW	3.38	450*71	4.45
180*60	0.56	K300*109	3.56	DW450*71	4.82
180*72	0.64	300*109N	3.32	450*73.5	4.57
180*72K	0.87	300*109W	3.21	450*76	5.27
H180*72	0.77	320*52.5	1.69	450*81.5	5.24
190*60	0.59	320*54	1.81	450*81N	5.19
190*60	0.59	B320*84	2.95	450*81W	5.02
190*72	0.72	B320*86	2.99	450*83.5	5.47
200*72	0.84	B320*86SB	2.99	450*83.5Y	5.67
200*72K	1.07	B320*86C	3.01	450*84	4.22
230*48	0.87	B320*86Z	3.12	B450*86	4.33
230*48K	1.06	B320*86CM	3.01	B450*86SB	4.3
230*72	1.09	B320*86R	2.99	B450*86C	4.31
230*72K	1.34	T320*86	3.22	B450*86Z	4.51
230*96	1.77	T320*86MB	3.3	B450*86CM	4.37
230*101	1.92	T320*86SB	3.27	B450*86R	4.3
250*47	1.11	T320*86C	3.25	450*90	4.07
250*48.5	1.13	T320*86Z	3.53	KU450*90	3.9
250*52.5	1.04	320*90	2.85	450*110	6.9
250*52.5K	1.31	320*100	2.67	T450*100MB	5.3
250*72	1.17	320*100W	3.01	T450*100	5.09
B250*72	1.03	320*106	3.63	T450*100SB	5.16
250*96	2.21	330*79	1.42	T450*100C	5.2
250*109	2.39	KU330*79	0.86	T450*100Z	5.55
260*55.5	1.48	330*84	1.23	450*163	10.47
260*96	1.91	350*52.5	1.85	485*92W	7.62
260*109	2.16	350*54.5	2.31	500*71	7.5
280*72	1.43	350*56	2.05	500*90	5.38
280*106	3.05	350*75.5	3.58	500*92	7.81
300*52.5KB	1.67	350*90	1.85	500*92W	8.6
300*52.5KW	1.71	350*100	3.69	500*100	6.34
300*52.5N	1.44	350*108	3.92	500*146	9.97
300*52.5W	1.56	350*109	4.12	600*100	8.3
JD300*52.5N	1.54	370*107	4.68	600*125	10.39
K300*52.5	1.72	400*72.5KB	3.44	650*110	13.34
KB300*52.5N	1.55	400*72.5KW	3.72	650*120	13.75
300*53	1.81	400*72.5N	3.48	650*125	15.8
300*55	1.88	400*72.5W	3.85	700*100	10.9
300*55.5	1.95	400*72.5Y	3.62	700*125	14.29
300*71	3.31	400*74	3.4	750*150	21.34
300*72	1.77	400*75.5	4.09	800*125	19.14
BA300*72	1.16	400*86	4.14	K800*150	21.55
		400*90	2.22	M800*150	20.05
ASV TRACK		400*107	4.95	900*150	31.23
280*102*37	1.36	400*142	7.12	1000*150	33.3
380*102*42	1.9
460*102*51	2.41	PAVER TRACK		SPECIAL TRACK
460*102*56	2.49	356*152.4*46	4.81	160*87.63*28	0.41
460*102C*51	2.44	483*152.4*52	6.07	240*87.63*28	0.51
510*102*51	2.6	460*225*36	7.79
