Electric Russia Concrete Vibrator Hand-Held

Ningbo Ace Machinery Co., Ltd.
  • Type：Concrete Vibrator
  • Shotcrete Type：Semi-Dry
  • Machining Process：Assembly
  • Structure：Rotor Type
  • Productivity：25m²,h
  • Vibrating Amplitude：1.0mm

Base Info

  • Model NO.：ZID-UL-200R
  • Certification：CE
  • Condition：New
  • Color：,
  • Product Name：High Frequency Concrete Vibrator
  • Power：2000W
  • Speed：18000rpm
  • Weigth：6.35kgs
  • Packing Size：45*48*25,2PCS
  • Transport Package：Carton
  • Specification：5.0HP
  • Trademark：ACE
  • Origin：Ningbo, China
  • HS Code：84306100
  • Production Capacity：1000PCS,Year

Description

High-Frequency  Concrete  Vibrator TypeHigh-frequencyModelZID--200Rated input power2000WRated voltage220VRated Frequency50HZNo-load speed18000 r/minWeight6.35kgsPacking size46*23*22cm


High-frequency vibrator shaftModel¢(mm)ZX-35ZX-38ZX-45ZX-50Diameter of head¢(mm)35384550Length of headL (mm)330370390410Vibrating Frequency(HZ)200200200200Vibrating Ampitude(mm)0.911.11.21.3Diameter of flexiable hoseD(mm)30303030Diameter of flexiable shaftD(mm)10101010Length(mtr)Form 3.0mtr to 6mtr packing sizecm75*75*5.5cm
