• Model NO.：Dh17-B2
• Condition：New
• Color：Yellow
• Operating Weight (Kg)：17500 Kg,19360 Kg
• Ground Pressure (Kpa)：64
• Engine Model：Weichai Wd10g190e214
• Rated Power/Rated Speed (Kw/Rpm)：140,1900
• Forward Speed (Km/H)：0-10
• Reversing Speed (Km/H)：0-10
• Ground Length(mm)：2675
• Specification：5250*3420*3080
• HS Code：8429521200
• Production Capacity：1000,PCS

Basic Info.

Model NO. Dh17-B2 Condition New Color Yellow Operating Weight (Kg) 17500 Kg/19360 Kg Ground Pressure (Kpa) 64 Engine Model Weichai Wd10g190e214 Rated Power/Rated Speed (Kw/Rpm) 140/1900 Forward Speed (Km/H) 0-10 Reversing Speed (Km/H) 0-10 Ground Length(mm) 2675 Specification 5250*3420*3080 HS Code 8429521200 Production Capacity 1000/PCS

Product Description

Shantui Dh17-B2 China Dozer Crawler Bulldozer

Features:

1. Weichai mechanical engine conforms to the China-II non-road machinery emission regulation, featuring high intelligence and efficiency, simple structure, high parts interchangeability, and low maintenance cost.

2. The intelligent match technology can achieve best working efficiency and most reasonable fuel economy, with the composite fuel consumption reduced by 10~15%.

Parameter name	DH17 B2 XL	DH17 B2 LGP
Performance parameters
Operating weight (Kg)	17500(Ripper not included)	19360
Ground pressure (kPa)	64	30
Engine
Engine model	Weichai WD10G190E214	Weichai WD10G190E214
Rated power/rated speed (kW/rpm)	140/1900	140/1900
Overall dimensions
Overall dimensions of machine (mm)	5250*3420*3080	5340*4150*3091
Driving performance
Forward speed (km/h)	0~10	0~10
Reversing speed (km/h)	0~10	0~10
Chassis System
Center distance of track (mm)	1880	2350
Width of track shoes (mm)	510/560/610	1100/950
Ground length(mm)	2675	2935
Tank capacity
Fuel tank (L)	305	305
Working device
Blade type	Semi-U/Straight-tilt	Straight-tilt
Digging depth (mm)	520	485
Ripper type	3 shank	-
Ripping depth (mm)	475	-
