• Model NO.：SL50WN
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Operating Weight：17100kg
• Related Loading：5000kg
• Bucket Capacity：3.0 M3
• Maximum Lifting Force：185 Kn
• Static Tipping Load (Full Turn)：10000 Kg
• Dumping Height Standard：3200mm
• Rated Power：162 Kw
• Transport Package：Nude
• Specification：5ton
• Trademark：Shantui
• Origin：Shandong
• HS Code：845464654
• Production Capacity：100units,Month

ITEM

SL50WN

Engine

Weichai WD10G220E23

Rated power (kW/rpm)

162/2000

Displacement (L)

9.726

Minimum diesel consumption
(g/kWh)

215

Ma×imum torque (NM)

900

Operating weight (kg)

17000

Dimension L×W×H (mm)

8054×3072×3410

Center distance of tires (mm)

2250

Wheel base (mm)

3250

Loading capacity (t)

5

Bucket capacity (m3)

3

Ma×imum traction force (KN)

162

Ma×imum breakout force (KN)

185

Static tipping load (full turn) (kg)

10000

Gradeability (°)

30

Minimum turning radius (mm)

Outside of bucket

6590

Outside of tire

7256

Turning angle (°)

36

Dumping height (mm)

Standard Arm

3178

E×tended

3350

Long

3676

Dumping reach (mm)

Standard Arm

1160

E×tended

1110

Long

954

Lifting/Lifting,dumping and lowering time (S)

54/109

Travel speed (km/h)

Forward 1

0-13 or 0-8

Forward 2

0-38 or 0-15

Forward 3

(n/a)or 0-24

Forward 4

(n/a) or 0-38

Reverse 1

0-17 or 0-8

Reverse 2

(n/a) or 0-24

Reverse 3

-
