Asphalt Road Mini Cold Milling Machine Xm503
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Cold Milling Machine
- Object：Asphalt Concrete Pavement
- Moving Type：Mobile
- Mixing Method：Intermittent Compulsory
- Automatic Grade：Automatic
- Product Capacity：<40t,h
Base Info
- Model NO.：Xm503
- Certification：ISO9001: 2000, CE
- Condition：New
- Maximum Milling Width：500mm
- Maximum Milling Depth：180mm
- Engine Model：Sc4h-C125
- Number of Tools：54
- Rated Power：93kw
- Drum Diameter with Tools(mm)：660
- Transport Package：Nude
- Specification：3785*1765*3346mm
- Origin：China
- HS Code：84294019
- Production Capacity：1000,PCS
Description
Basic Info.
Model NO. Xm503 Certification ISO9001: 2000, CE Condition New Maximum Milling Width 500mm Maximum Milling Depth 180mm Engine Model Sc4h-C125 Number of Tools 54 Rated Power 93kw Drum Diameter with Tools(mm) 660 Transport Package Nude Specification 3785*1765*3346mm Origin China HS Code 84294019 Production Capacity 1000/PCSProduct Description
Asphalt Road Mini Cold Milling Machine Xm503
Shangchai 93KW Engine
All three wheel driving
Single front wheel steering structure
International brand pump,motor,reducer
Most suitable for municipal road maintenance
| Model | XM503 |
| Max. milling width(mm) | 500 |
| Max. milling depth(mm) | 180 |
| Tip distance (mm) | 12 |
| Number of tools | 54 |
| Drum diameter with tools(mm) | 660 |
| Engine Model | SC4H-C125 |
| Engine Manufacturer | Shangchai |
| Rated speed(rpm) | 2200 |
| Rated power(kW) | 93 |
| Fuel tank(L) | 140 |
| Water tank(L) | 300 |
| Operating speed(m/min) | 0-40 |
| Travel speed(km/h) | 0-6 |
| Groundability(%) | 60% |
| Maximum discharge height(mm) | 1250 |
| Theoretical discharge capacity (m³/h) | 80 |
| Operating weight Kg | ≤8000 |
| Min. milling radius (mm) | 350 |
| Ground clearance(mm) | 160 |
| Dimension LxWxH(mm) | 3785*1765*3346 |
| Belt conveyor LxWxH(mm) | 1800*800*600 |
