• Model NO.：6126E
• Compaction Depth：.
• Engine Type：Diesel Engine
• Travel Speed：2.7-11km,H
• Centrifugal Force：26ton Road Roller 6126e with 140 Kw,1800 Rpm Engin
• Certification：CE, ISO 9001:2000
• Condition：New
• Operating Mass：26000 Kg
• Mass on Vibrating Drum：13000 Kg
• Mass on Drive Axle：13000 Kg
• Front Drum Static Linear Load：6658 mm
• Engine Model：Sc8dk190.2g3
• Emission Regulation：Stage III
• Rated Power：140 Kw,1800 Rpm
• Vibration Frequency：28,33Hz
• Nominal Amplitude：2.0 , 1.0 mm
• Drum Diameter：1700 mm
• Min. Groundclearance：430 mm
• Wheelbase：3270mm
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：6658 mm*mm*2440*mm*3150*mm
• Trademark：SINOMADA
• Origin：China
• Production Capacity：300piece,Month

• Flexible and non-impact technology on our vibratory rollers extends the vibratory bearing's working life to beyond 10,000 hours increasing productivity and reducing part wear.
• With a larger diameter drum, combined with amplitude consistency and uniformity, we ensure that the optimum compaction force is delivered with fewer passes required.
• Patented cooling technology inside the drum keeps temperatures balanced at around 90° centigrade, 20° lower than the industry average. This stable temperature regulation helps prolong component life and reduces maintenance.

Specifications  6120E:

Operating Mass

26000 kg

Mass On Vibrating Drum

13000 kg

Mass On Drive Axle

13000 kg

Front Drum Static Linear Load

591 N/cm

Model

Shangchai SC8DK190.2G3

Emission Regulation

Stage III

Rated Power

140 kW (190 hp) @ 1800 rpm

Vibration Frequency

28/33 Hz

Nominal Amplitude

2.0/1.0 mm

Centrifugal Force

430/300 kN

Drum Diameter

1700 mm

1st Maximum Speed, fwd

2.7 km/h

2nd Maximum Speed, fwd

5.2 km/h

3rd Maximum Speed, fwd

11 km/h

Theoretical Gradeability

30%

Min. GroundClearance

430 mm

Wheelbase

3270 mm

Min. Outside Turning Radius

7000 mm

Overall Length

6658 mm

Overall Width

2440 mm

Overall Height

3150 mm

Detailed Images:
