• Model NO.：FR150D
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Dimension：7700*2505*2850mm
• Engine：Isuzu
• Power：72.7kw,2200rpm
• Operating Weight：13850kg
• Transport Package：Nude Package
• Specification：small
• Trademark：LOVOL
• Origin：China
• Production Capacity：300units,Month

Main Parameters7700*2505*2850Operation Weight (Standard Configuration) (KN)13850Standard Bucket Capacity0.6Transport Dimensionsmm7700*2505*2850Bucket Digging Force (KN)93.2Bucket Rod Digging Force (KN)69Maximum Traction (KN)112DeviceMax. Walking Speed (Km/h)5.4Climbing Performance(°)35Total Length of the Crawler3730Tail Turning Radius (mm)2270Width of the Crawler500Ground Pressure (Kpa)38Turning MechanismTurning Speed (rpm)11.5EngineModelISUZU BB-4BG1TRPTypeFour Cylinders, Direct Injection, Water-cooling, Overhead Valve, turbochargerRated Power/Rotate Speed (KW/rpm)72.7/2200Rated Torque/Rotate Speed (N.m/rpm)337.6/1600Cylinder Diameter*Stroke (mm)105*125Output Value (L)4.3Fuel Consumption (g/KW.h)240Fuel Tank Capacity (L)246Hydraulic SystemMain Pump Pressure (Mpa)25.5Main Pump Flow Operating ScopeMaximum Digging Height (mm)8500Maximum Dumping Height (mm)6080Maximum Digging Depth (mm)5435Maximum Digging Radius (mm)8300OptionalBreaking Hammer& Standard Bucket & Earthmoving Bucket & Rock-moving Bucket
