Latest Type Mini Wheel Loader Backhoe Russia Euro Backhoe for Sale
Jining Nicosail Machinery Co., Ltd.- Certification：ISO, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：Conventional type,European type,Tractor type
- Type：Medium-sized Loader
- Transmission Type：Hydraulic
- Braking System：Air Assist
- Travel Speed：0 - 30 Km,H
- Gradeability：30 Degree
- Working Pressure：16 MPa
- Min. Turning Radius：3500-4500mm
- Tire Pressure：250 Kpa
- Power：40-92kw
- Rated Loading：1500-3000kg
- Bucket Capacity：0.1-0.3cbm
- Machine Type：Conventional,European Type,Upgraded Type,Tractor T
- Transport Package：Standard Export Packaging
- Trademark：NICOSAIL
- Origin：Shandong, China
- HS Code：8429510000
- Production Capacity：100,Month
Description
Excavation ParametersBucket Capacity 0.16-0.19cbm 0.16-0.3cbm Max. Excavation Depth 3200mm 3500mm Max. Excavation Height 4100-4330mm 4200-4500mm
| Model | LW-6 | LW-7 | LW-8 | LW-9 | LW-10 | LW-12 |
| Matched Power | 25-35 hp | 40-75 hp | 45-85hp | 50-100 hp | 70-125hp | 80-150hp |
| Max Digging Deep | 1850 mm | 2150 mm | 2640 mm | 2900 mm | 3000 mm | 3500 mm |
| Max Digging Height | 2500 mm | 3400 mm | 3510 mm | 3900 mm | 4000 mm | 4300mm |
| Max moving Height | 1400 mm | 1760 mm | 2000 mm | 2327mm | 2362 mm | 2700mm |
| Unloading height | 1733 mm | 1878 mm | 1952 mm | 2413 mm | 2540 mm | 2770mm |
| Max Digging Radius | 2800 mm | 3360 mm | 3930 mm | 3977 mm | 3986mm | 4300 mm |
| Digging power | 1300 kg | 1200 kg | 1600 kg | 1900 kg | 2600 kg | 2700kg |
| Arm's power | 790 kg | 950 kg | 1000 kg | 1270 kg | 1720 kg | 1900kg |
| Bucket work angle | 160° | 160° | 160° | 150° | 150° | 172° |
| Swing Angle For Boom | 140° | 140° | 140° | 160° | 160° | 180° |
| Working pressure | 16 Mpa | 16 Mpa | 16 Mpa | 16 Mpa | 16 Mpa | 16 Mpa |
| Bucket Width | 300 mm | 400 mm | 450 mm | 480 mm | 500 mm | 550 mm |
| Bucket Cubage | 0.03 m3 | 0.036 m3 | 0.048 m3 | 0.054 m3 | 0.06 m3 | 0.07 m3 |
