• Model NO.：Ty230
• Engine Power：74~147kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Machine Weight：25500 Kg
• Max.Lift Above Ground：1210 mm
• Rated Speed：1800 R,Min
• Engine Model：Cummins Nt855-C280
• Rated Power (Kw)：175
• Transport Package：Comply with Export Packaging Requirements
• Specification：5459*3725*3380 mm
• Trademark：Raygoo
• Origin：Fujian, China
• HS Code：84295100
• Production Capacity：5000

Overview Product DescriptionDetailed Photos



Product Parameters Specification/Blade typeStraight-tiltAngleU-BladeOperating Weight(kg)174001770017900Min.Ground Clearance(mm)400400400Min.Tuming Radius(m)3.23.23.2Ground Pressure(MPa)0.0690.0700.071Track Gauge(mm)188018801880Max.Pulling Force(KN)142142142Grade Ability(°)303030Blade Capacity(m³)4.54.38.6Blade WidthxHeight(mm)3416x11453970x10374061x1386Max.Lift(mm)111010951095Max.Depth(mm)530545545Max.tilt Adjustment(mm)≥860≥400≥400Pitch Adjustment(°)555555Capability(m³/H)(Theoreticalvalue 40m)247247260Weight Of Blade(kg)235024502560ENGINEModel&Type Cummins NT855-C280S10/Shangchai SC11CB200G2B1/Weichai WD 10G200E25,6-cylinder,
in-line,vertical.water-cooled.4-stroke-cycle,turbo-charged,over valve directs injectionRated Revolution(rpm)1850Flywheel Horsepower(HP)160Cylinder Number-BoreX Stroke(mm)Cummins :6-139.7x152.4Shangchai:6-120.6x152.4Weicha i:6-126x130Piston Displacement(L)1410.59.73Min.Fuel Consumption(g/kW.h)212223223Max.Torque(Nm/rpm)877/1250830/1100830/1100Starting MethodStarting motor 24V 7.5KWOur machines advantages

Why choose RAYGOO GROUP

1. Quality assurance
2. Multi-currency payment ( RMB / USD / EUR) & Multi Payment team: T/T, L/C at sight....
3. Cheap shipment costs, Rich container package & Fast shipment:
Raygoo group cooperated with many shipping company many years, which can get the cheapest ocean freight with latest shipping date, even whole shipping tracking.

4. Long-term spare parts support:
Since 2015, in order to effectively solve our customers spare parts demand, we built a spare parts department, which get high speaking feedback from our clients.

5. Long-term technical service support:
We have a professional technical team which provide technical support for our domestic or oversea clients. If clients have some technical problems which can't deal with it by self, we can provide video support or door to door support.
6. Door and door service:
Till now, we can support door and door assembling service if they can't assemble it when container arrived in some countries,such as Philippines, Zimbabwe, Mozambique, Kenya, Cambodia, Indonesia.... If the quantity is large, even can provide engineer indoor support.


7. Rich brands:
As we worked on construction machines more than 15 years, which already build nice strategic relationship with world brand company for competitive price and quality.support

FAQ

Q: What is your delivery time?
A: For standard machine, the delivery time is Within 25-35 days after receiving the down payment.It also depends on the models and the quantity of your order.
     In peak season,the production may take longer.

Q: What is the payment term?
A: Normally we accept L/C, or T/T 30% down payment, balance to be paid against BL copy and loading pictures.

Q: What color can I choose?
A: There are Yellow, Red, Blue, Black, White, Orange,and Green. We can customize the color when you order more.

Q: What kind of service can I get from you? How can I get spare parts?
A: We have 1 year warranty for each brand new machine, within 1 year, if any parts broken because of quality issues, the new parts would be sent to you free of charge by DHL, within 7 working days. Besides of the warranty policy, our professional after-sales team responds quickly to any kind of using problems, replacement parts supply could be guaranteed for a life time.
