• Model NO.：Xmr083
• Travel Speed：0-3.6
• Certification：CS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Weight：800kg
• Drive System：Hydraulic Drive
• Engine Speed：2600r,Min
• Transport Package：Suitable for Ocean Shipment
• Specification：2695*708*1195mm
• Origin：China
• HS Code：84294011
• Production Capacity：1000 Set Per Month

Basic Info.

Model NO. Xmr083 Travel Speed 0-3.6 Certification CS, ISO 9001:2000, ISO 9001:2008 Condition New Weight 800kg Drive System Hydraulic Drive Engine Speed 2600r/Min Transport Package Suitable for Ocean Shipment Specification 2695*708*1195mm Origin China HS Code 84294011 Production Capacity 1000 Set Per Month

Product Description

Official  Widely Used Mini Vibratory Hand Roller Xmr083

Product Description

XMR083 is walk-behind double drum vibratory roller with operating mass of 0.8 tons, has features such as high performance and comfortable operation. It is mainly used for compacting asphalt concrete surface layer, especially for urban roads, stadiums and other minor works. Can also be used for small and medium base, sub base and compacted materials. Has good edge compaction performance, in narrow job sites and groove-based shows its unique advantages.

Parameter



ITEMS	XMR083
Operating weight kg	800
Roller diameter mm	400
Roller width mm	708
Speed range km/h	0~3.6
Theoretical gradeability %	30
Minimum turning radius outside mm	3135
Minimum ground clearance mm	250
Wheelbase mm	720
Steering angle	±15°
Vibration frequency Hz	55
Nominal amplitude mm	0.32
Exciting force kN	15.8
Engine model	186FA
Rated Speed r/min	2600
Rated Power kW	5
Engine Fuel Consumption g/kW.h	280
Dimensions(length/width/height)mm	2695×760×1200
Hydraulic oil tank L	16
Fuel tank capacity L	5.5
Sprinkler tank capacity L	40



Product Show
