High Efficiency Two Wheeled Acntruck 6516e Double Drum Road Roller

Acntruck Automobile Sales (Shanghai) Co., Ltd.
  • After-sales Service：Field Installation, Commissioning and Training
  • Warranty：1 Year
  • Type：Road Roller
  • Working Method：Steel Wheel
  • Axle：Triaxial Three-Wheel
  • Grinding Wheel Type：Tire Grind

Base Info

  • Model NO.：6516E
  • Compaction Depth：40cm
  • Engine Type：Diesel Engine
  • Travel Speed：40cm,s
  • Centrifugal Force：40KN
  • Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Max. Operating Mass：16000 Kg
  • Min. Operating Mass：11000 Kg
  • Single Tire Load：1778 Kg
  • Emission Regulation：Stage II
  • Rated Power：97 Kw , 2200 Rpm
  • Working Speed：0-7 Km,H
  • Traveling Speed：0-16 Km,H
  • Compacting Width：2250 mm
  • Theoretical Gradeability：20%
  • Min. Ground Clearance：290 mm
  • Transport Package：Nude Package
  • Trademark：LIUGONG
  • Origin：China
  • Production Capacity：50 Unit Per Month

Description

Max.Operating Mass16000 kgMin.Operating Mass11000 kgSingle Tire Load1778 kgOverlapping of Front&Rear Tire45 mmEmission RegulationStage IIRated Power97kw/2200rpmWorking Speed0-7 km/hTraveling Speed0-16 km/hCompacting Width2250 mmTheoretical Gradeability20%Tire NumbersFront 4 Rear 5High Efficiency Two Wheeled Acntruck 6516e Double Drum Road RollerHigh Efficiency Two Wheeled Acntruck 6516e Double Drum Road RollerPacking Pictures
