Shantui Se215 21 Ton Long Arm Crawler Excavator Factory Price

Sinomada Heavy Industry (Changsha) Co., Ltd.

After-sales Service：1 Year
Warranty：1 Year
Type：Crawler Excavator
Usage：Special Excavator
Bucket：Grab Shovel
Transmission：Hydraulic Transmission

Base Info

Model NO.：SE215
Drive Type：Internal Combustion Drive
Bucket Capacity：1.0~1.5m³
Size：Medium-Sized
Certification：CE, ISO9001: 2000
Condition：New
Engine Model：Qsb7 (China-III)
Transport Package：Roro
Specification：20800kg
Trademark：shantui
Origin：China
HS Code：8429521200
Production Capacity：500,Month

Description

Comparative itemSE215 (Standard version)Overall dimensions Overall length (mm)9625Ground length (During transport) (mm)4915Overall height (To the top of boom) (mm)3075Overall width (mm)2800Overall height (To top of cab) (mm)3055Ground clearance of counterweight (mm)1075Minimum ground clearance (mm)470Tail turning radius (mm)2925Track length (mm)4140Track gauge (mm)2200Track width (mm)2800Standard track shoe width (mm)600Turntable width (mm)2725Distance from slewing center to tail (mm)2920Working range Maximum digging height (mm)10095Maximum dumping height (mm)7190Maximum digging depth (mm)6490Maximum vertical digging depth (mm)5915Maximum digging distance (mm)9860Maximum digging distance at ground level (mm)9675Working device minimum turning radius (mm)2970Maximum lifting height of bulldozer blade (mm)-Maximum digging depth of bulldozer blade (mm)-Engine ModelFamous Brand QSB7 (China-III)Type6-cylinder, high pressure common rail, and water-cooled and turbochargedDisplacement (L)6.7Rated power (kW/rpm)124/2050Hydraulic system Type of hydraulic pumpVariable displacement duplex plunger pumpRated working flow (L/min)2x213Bucket Bucket capacity (m³)0.9Swing system Maximum swing speed (r/min)11Brake typeMechanically applied and pressure releasedDigging force Bucket arm digging force (KN)135/146Bucket digging force (KN)99/107Operating weight and ground pressure Operating weight (kg)20800Ground pressure (kPa)47.5Traveling system Traveling motorAxial variable displacement plunger motorTraveling speed (km/h)3.15/5.15Traction force (KN)214Gradeability70%(35°)Tank capacity Fuel tank capacity (L)330Cooling system (L)28Engine oil capacity (L)22Hydraulic oil tank/system capacity (L)270/400
