Shantui 162kw Wheel Loader Zl50gn SL50wn Clg856h Clg855h with 3cbm Bucket Capacity
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service:-
- Warranty:12 Months
- Certification:ISO, CE
- Condition:New
- Rated Load:18 Ton
- Transmission:Power
Base Info
- Model NO.:SL50WN
- Load and Unload Mode:Front Discharge
- Walking Mode:Wheeled
- Type:Medium-sized Loader
- Operating Weight (Kg):17100
- Engine Model:Wd10
- Rated Power/Rated Speed (Kw/Rpm):162,2000
- Forward Speed (Km/H):F1:0-13,F2:0-38
- Center Distance of Track (mm):3250
- Fuel Tank (L):220
- Transport Package:Nude
- Specification:8025*3026*3410 mm
- Origin:Shandong, China
- HS Code:8429510000
- Production Capacity:100,Month
Description
Weichai new generation Blue Engine II energy-saving engine WD10G220E23 conforms to China-II emission regulation and reduces the failure rate by 30% and saves the fuel by >10%.
Moderate Wheelbase
It guarantees outstanding site adaptability and flexibility and strong operating stability and can handle common heavy-load operations with ease.
De-noising
The low-speed engine and new cab are applied and the engine hood is installed with additional sound-insulating material to further reduce the engine noise to 85dB, which is far lower than the current noise standard (89dB) and is superior to the 86dB requirement of the national mandatory standard implemented in 2015.
Parameter
Parameter name | SL50WN |
Performance parameters | |
Operating weight (Kg) | 17100 |
Maximum dumping height (mm) | 3330 (Extended boom)3700 (Long Boom) |
Dumping reach (mm) | 1230 (Extended boom)1270 (Long Boom) |
Maximum breakout force (kN) | ≥185 |
Total cycle time (s) | 10.6 |
Engine | |
Engine model | WD10 |
Rated power/rated speed (kW/rpm) | 162/2000 |
Overall dimensions | |
Overall dimensions of machine (mm) | 8025*3026*3410 |
Driving performance | |
Forward speed (km/h) | F1:0-13,F2:0-38 |
Reversing speed (km/h) | R1:0-17 |
Chassis System | |
Wheelbase (mm) | 3250 |
Tank capacity | |
Fuel tank (L) | 220 |
Working device | |
Rated bucket capacity (m³) | 3 |
Rated loading capacity (t) | 5 |
